6.3.7 Status confirmation frame

The status confirmation frame displays the status of a unit on which an operation was performed by using an operation button. The background is always pale yellow. The status confirmation frame is not displayed unless it has been set to be displayed in the user environment settings. For details on how to enable or disable the status confirmation frame, see 4.2 Environment defined in the user environment settings file.

The following figure shows the status confirmation frame.

Figure 6-17 Status confirmation frame

Organization of this subsection

(1) Status list

(2) Error information list

(3) Buttons

(4) Auto refresh toggle check box

(5) Display items

(1) Status list

The displayed items are the same as those in the statuses frame. For details, see 6.3.4 Statuses frame.

(2) Error information list

The displayed items are the same as those in the statuses frame. For details, see 6.3.4 Statuses frame.

(3) Buttons

Refresh button

Displays the latest information in the status list.

Display Selected on Status View button

Changes the display to the statuses frame that shows only the operation target for which the Select check box is selected in the status confirmation frame. If you choose the Display Selected on Status View button without selecting a Select check box, an error dialog box appears.

This button is not displayed when the status list contains no records.

(4) Auto refresh toggle check box

Select the Stop auto refresh check box to temporarily stop auto refresh processing for the status confirmation frame. Clear the check box to resume auto refresh processing for the status confirmation frame.

(5) Display items

The frame displays the units for which operation was performed this time. The frame does not contain the units for which execution of a nested jobnet or job was canceled by using the Execution Prohibited button in the previous operation and then ended normally.
