15.2.1 Page transitions in Job Portal

The following figure shows the screen transitions in the job portal.

Figure 15‒1: Screen transitions in job portal

The following table lists the screens and dialog boxes of the job portal and the sections related to them:

No.	Screen	Relevant section
1	Dashboard screen	15.2.2
2	List screen	15.2.3
3	Execution Agent screen	15.2.4
4	Monthly Schedule screen	15.2.7
5	Monitor dialog box	15.2.8
6	Monitor screen	15.2.9
7	Execution Generation dialog box	15.2.10
8	Set Monitoring Targets dialog box	15.2.11
9	Generation Selection dialog box	15.2.12
10	Rerun dialog box	15.2.13
11	Change Job Status dialog box	15.2.14
12	Detail Information dialog box	15.2.15
13	Define Details dialog box	15.2.16
14	Execution Result Details dialog box	15.2.17
15	Inherit Result dialog box	15.2.18
16	Register for Execution dialog box	15.2.19
17	Register Passing Information dialog box	15.2.20
18	Variables Used dialog box	15.2.21
19	Cancel Registration dialog box	15.2.22
20	Add dialog box	15.2.23
21	Change Time dialog box	15.2.24
22	Execute Immediately dialog box	15.2.25
23	Change Delay Monitor Temporarily dialog box	15.2.26
24	View Temporary Changes to Delay Monitor dialog box	15.2.27
25	Change Display Month dialog box	15.2.28
26	Setting dialog box	15.2.29
27	Apply Operating Permission Settings dialog box	15.2.30
28	Wait Conditions Statuses dialog box	15.2.31
29	Connection Information dialog box	15.2.32
30	Detail Information dialog box (for an execution agent)	15.2.33
31	Add Execution Agent dialog box	15.2.34
32	Change Execution Agent Settings dialog box	15.2.35
33	Change the Job Transfer Restriction Status of the Execution Agent dialog box	15.2.36
34	Change the Execution Agent Status dialog box	15.2.37
35	Check the Communication Status of the Execution Agent dialog box	15.2.38
36	Add Time Period and Job-Execution Multiplicity Level dialog box	15.2.39
37	Operating status of execution agent dialog box	15.2.40
38	Operating status in a day dialog box (for an execution agent)	15.2.41
39	Execution Status dialog box	15.2.42
40	Units from which information could not be acquired dialog box	15.2.43
41	Detail Information dialog box (for an execution agent group).	15.2.44
42	Job Execution Status dialog box	15.2.45
43	Add Execution Agent Group dialog box	15.2.46
44	Change Settings of Execution Agent Group dialog box	15.2.47
45	Attach Relation to Execution Agent Group dialog box	15.2.48
46	Attach Relation to Execution Agent dialog box	15.2.49
47	Change the Priority Order dialog box	15.2.50
48	Change the Job Transfer Restriction Status of the Execution Agent Group dialog box	15.2.51
49	Processing status dialog box	15.2.52
