8.18.2 Trace collection points of the JMS Connection interface and the trace information that can be collected
- Organization of this subsection
(1) Trace collection points and PRF trace collection levels
The following table describes the event IDs, trace collection points, and PRF trace collection levels.
|
Event ID |
Number in the figure# |
Trace collection point |
Level |
|---|---|---|---|
|
0xA60E |
1 |
When the processing of Connection.createSession(transacted,acknowledgeMode) starts |
A |
|
0xA60F |
4 |
When the processing of Connection.createSession(transacted,acknowledgeMode) ends |
A |
|
0xA610 |
1 |
When the processing of QueueConnection.createQueueSession(transacted,acknowledgeMode) starts |
A |
|
0xA611 |
4 |
When the processing of QueueConnection.createQueueSession(transacted,acknowledgeMode) ends |
A |
|
0xA612 |
1 |
When the processing of TopicConnection.createTopicSession(transacted,acknowledgeMode) starts |
A |
|
0xA613 |
4 |
When the processing of TopicConnection.createTopicSession(transacted,acknowledgeMode) ends |
A |
|
0xA614 |
5 |
When the processing of Connection.close() starts |
A |
|
0xA615 |
8 |
When the processing of Connection.close() ends |
A |
|
0xA616 |
2 |
Invocation by CJMSP Broker immediately before creating the session |
A |
|
0xA617 |
3 |
Invocation by CJMSP Broker just after creating the session |
A |
|
0xA618 |
6 |
Invocation by CJMSP Broker immediately before disconnection |
A |
|
0xA619 |
7 |
Invocation by CJMSP Broker just after disconnection |
A |
- Legend:
-
A: Standard
- #
-
Corresponds to the numbers in Figure 8-72.
The following figure shows the trace collection points of the JMS Connection interface.
|
|
![[Figure]](GRAPHICS/ZU077500.GIF)
(2) Trace information that can be collected
The following table describes the trace information that can be collected for the JMS Connection interface.
|
Number in the figure# |
Event ID |
Level |
Information that can be collected |
||
|---|---|---|---|---|---|
|
Interface name |
Operation name |
Option |
|||
|
1 |
0xA60E |
A |
Transaction |
Ack mode |
-- |
|
0xA610 |
A |
||||
|
0xA612 |
A |
||||
|
2 |
0xA616 |
A |
-- |
-- |
-- |
|
3 |
0xA617 |
A |
-- |
-- |
-- |
|
4 |
0xA60F |
A |
-- |
-- |
-- |
|
0xA611 |
A |
||||
|
0xA613 |
A |
||||
|
5 |
0xA614 |
A |
-- |
-- |
-- |
|
6 |
0xA618 |
A |
-- |
-- |
-- |
|
7 |
0xA619 |
A |
-- |
-- |
-- |
|
8 |
0xA615 |
A |
-- |
-- |
-- |
- Legend:
-
A: Standard
--: Not applicable
- #
-
Corresponds to the numbers in Figure 8-72.
- Important note
-
The event IDs 0xA618 and 0xA619 are also output when the Message-driven Bean applications are not running.
- Reference note
-
The Acknowledgement mode is output using a numerical value. The numerical value is mapped to the types of Acknowledgement modes. The mapping is as follows:
-
AUTO_ACKNOWLEDGE = 1
-
CLIENT_ACKNOWLEDGE = 2
-
DUPS_OK_ACKNOWLEDGE = 3
-
SESSION_TRANSACTED = 0
The numerical values of the respective modes are defined in the JMS specifications.
-
