6.5.10 Using NOT operation

Execute NOT operation by considering the input value as hexadecimal character string. If input value is other than hexadecimal character string, error value (NaN) is returned. If input value exceeds 64 bit, round the bits more than 64 bits.

At the time of transformation source node, function is converted to character string at the time of executing transformation.

Organization of this subsection
(1) Function used
(2) Setting procedure

(1) Function used

Use NOT operation functionto execute NOT operation. Following figure shows the usage example:

Figure 6-11 FigureNOT operation function usage example

[Figure]

(2) Setting procedure

Procedure for setting up the NOT operation is as follows:

  1. Select NOT operation function (not) from the pallet and deploy to the Mapping viewer.
  2. Set the mapping line.
  3. Display NOT operation dialog with any of the following methods:
    • Right click the NOT operation function and select Settings.
    • Double click the NOT operation function.
    NOT operation dialog is displayed.

For details on [NOT operation] dialog, see "1.6.25 NOT Operation dialog " in "Service Platform Reference Guide".

  1. To specify input value of NOT operation in Input, click Select node button.
    Select node dialog is displayed.
  2. Specify node set, which is input value.
    Input value of NOT operation is set in Input.
  3. If you want to execute mapping only when you set conditions in input value specified in Input and those conditions are fulfilled, click Specify conditions button.
    Node conditions setting dialog is displayed.
    For details on how to specify node conditions, see "6.7 Specifying Node Conditions". For details on Specify node conditions dialog, see '1.6.9 Set Node Condition Dialog" in "Service Platform Reference Guide".
  4. When you want to specify a function of negation target in Input, click Select function button.
    Function selection dialog is displayed.

For details on Function selection dialog, see "1.6.7 Select function dialog" in "Service Platform Reference Guide".

  1. Click [OK] button.
