The following table describes the event IDs, trace collection points, and PRF trace collection levels.

Table 8-156 Details of trace collection points in CJMSP Broker when connecting to the CJMSP resource adapter

Event ID	Number in the figure#	Trace collection points	Level
0xA678	1	When the processing of ResourceAdapter.start(ctx) starts	A
0xA679	4	When the processing of ResourceAdapter.start(ctx) ends	A
0xA67A	5	When the processing of ResourceAdapter.stop() starts	A
0xA67B	8	When the processing of ResourceAdapter.stop() ends	A
0xA67C	2	Invocation by CJMSP Broker immediately before invoking the hello method	A
0xA67D	3	Invocation by CJMSP Broker just after invoking the hello method	A
0xA67E	6	Invocation by CJMSP Broker immediately before invoking the good bye method	A
0xA67F	7	Invocation by CJMSP Broker just after invoking the good bye method	A

Legend:

A: Standard

#

Corresponds to the numbers in Figure 8-97.

Note

The event IDs 0xA67C and 0xA67D are also output when CJMSP Broker and the CJMSP resource adapter are communicating in order to establish the connection.

The following figure shows the trace collection points in CJMSP Broker when connecting to the CJMSP resource adapter.

Figure 8-97 Trace collection points of CJMSP Broker when connecting to the CJMSP resource adapter

Trace information (interface name, operation name, and option) cannot be collected for CJMSP Broker when connecting to the CJMSP resource adapter.
