3.3.1 Checking inventory information
(1) Checking inventory information
To check inventory information:
- Use NNM to select a symbol for the inventory information you wish to check.
- From the Administration menu, choose Software Distribution Administration, and then View Inventory, and select the inventory information you wish to check.
JP1/Software Distribution Inventory Viewer is displayed, which allows you to check inventory information.
The following shows what JP1/Software Distribution Inventory Viewer looks like:
Figure 3-10 Example of JP1/Software Distribution Inventory Viewer
![[Figure]](FIGURE/CM20100.GIF)
- Menu bar
- File
- Closes JP1/Software Distribution Inventory Viewer.
- View
- Allows you to select the type of inventory information you want to check and to refresh inventory information.
- Help
- Displays JP1/Software Distribution version information.
- Toolbar
![[Figure]](FIGURE/CM20110.GIF)
: Displays software information.![[Figure]](FIGURE/CM20120.GIF)
: Displays system information.![[Figure]](FIGURE/CM20130.GIF)
: Displays user inventory information.![[Figure]](FIGURE/CM20140.GIF)
: Displays registry information.![[Figure]](FIGURE/CM20150.GIF)
: Refreshes inventory information.
- Information display area
- This area displays the selected inventory information.
- Status bar
- The display node displays the name (host name or IP address) of the relay system or client for which information is being displayed.
- The message displays the tool bar meaning and provides an explanatory message for the input item.
