1.3.1 Case 1: When configuring with the same settings of the database and Reliable Messaging, in the test environment and the production environment
When configuring with the same settings of the database and Reliable Messaging in the following test environment and production environments, the repository used in the test environment can be migrated to the production environment as it is:
-
When both database and Reliable Messaging are used in the test environment and in the production environment
-
When both database and Reliable Messaging are not used in the test environment and in the production environment
-
When database is used and Reliable Messaging is not used in the test environment and in the production environment
The following figure shows the procedure of migration when configuring with same settings of the database and Reliable Messaging, in the test environment and production environments:
|
|
![[Figure]](GRAPHICS/ZC010095.GIF)
For details about specific procedures for migrating, see "3.4.1 Procedure of migration when the existence of usage of the database and Reliable Messaging in the test and production environments is the same".
