6.3.17 Collecting condition definition file

server

Enter the collection target server name.

Specify a server name, host name or IP address within 255 bytes.

If you specify an IP address, use the IPv4 address or IPv6 address format.

rscid

Specify the collection target resource ID.

For details of the resource ID, see E. Resource IDs.

stime

Specify the collection start time for the resource. Specify this in the same format as the -stime option of the ssocolstart command.

When the specification is omitted, or the specified collection start time has already passed, the collection will be started when the command is executed.

ptime

Specify the collection end time for the resource. Specify this in the same format as the -ptime option of the ssocolstart command.

When both this key and the period key are omitted, this indicates that the resource collection condition will be collected indefinitely. Also, this key cannot be specified at the same time as the period key.

period

Specifies the resource collection end time, by the amount of time passed since the collection start time. Specify this in the same format as the -period option of the ssocolset command.

When both this key and the ptime key are omitted, this indicates that the resource collection conditions will be collected indefinitely. Also, this key cannot be specified at the same time as the period key.

stat_term_id

<<1>> ((1 to 10))

Specify the time zone ID of the time zone for which to calculate the initial value of the statistical threshold. When collection starts, an initial value is calculated for the same time zone ID as that of regular calculation. For other time zone IDs, an initial value is calculated for a specific time zone ID when the time zone ID of regular calculation is switched to the same one as that of the specific time zone ID. Specify this definition item for each resource ID.

stat_dbname

Specify the name of a master database or collection database.

stat_logfile

Specify an absolute path as the file name.^#

stat_masterlog

Specify the key name when you specify the master database on the local host.

stat_stime

((1980.01.01.00.00.00 to 2099.12.31.23.59.59))

Specify the start time of the statistical period. When this key is omitted, the start time is the same as the start time specified for the collection database. You cannot specify the same time as that specified in stat_ptime.

stat_ptime

((1980.01.01.00.00.00 to 2099.12.31.23.59.59))

Specify the end time of the statistical period. You cannot specify the same time as or an earlier time than the time specified in stat_ptime.

stat_time_zone

start time ((00:00:00 to 23:59:59))

end time ((00:00:01 to 24:00:00))

Specify the start time and end time of the time zone. Delimit each value with a semicolon (;). You can specify the start and end times for up to five time zones. When this key is omitted, no time zone is set and data will be extracted regardless of the time.

An error occurs in the following cases:

• Overlapping time zones are specified.

• The time zone start time is the same as the time zone end time.
