3.1.1 Default custom jobs

(1) List of default custom jobs

The following table lists default custom jobs.

Table 3‒1: List of default custom jobs

Default custom job name	Function
JP1FTP	This job works with JP1/FTP to transfer files.
JP1AMR3, JP1AMR3UX	This job works with JP1/AJS3 for Enterprise Applications to execute the background jobs of the SAP system.
JP1AMR3BW, JP1AMR3BWUX	This job works with JP1/AJS3 for Enterprise Applications to execute the info packages of the BW system.
JP1AMR3CP, JP1AMR3CPUX	This job works with JP1/AJS3 for Enterprise Applications to copy the background jobs of the SAP system.
ADSHPC, ADSHUX, ADSHAPPEXEC	This job works with JP1/Advanced Shell to execute the script file of JP1/Advanced Shell.
DHAJEW	This job works with JP1/DH - AJE to send and receive data to and from JP1/DH - Server.
CPALINK	This job works with JP1/CPA to start a job that has already been registered in JP1/CPA.

To Page Top

(2) Preparation for executing a default custom job

The preparation for executing a default custom job includes installing programs and registering the default custom job. Read the following for details.

• To use a default custom job, you need to install the following two programs:

  • Executable program for executing the default custom job

    You need to install the program to be linked in the host containing JP1/AJS3 - Manager or JP1/AJS3 - Agent that executes the default custom job.

  • Definition program for defining the default custom job, which is provided by the program to be linked

    If you install the program to be linked in a host different from JP1/AJS3 - View, you need to copy the definition program of the default custom job to the host where JP1/AJS3 - View exists.^#

    #: The availability of a definition program of a default custom job depends on the support status of the linked product. For details, see the manual or Release Notes for the linked product.

  The following figure shows the system configuration when using a default custom job.

  Figure 3‒1: System configuration when using a default custom job

• You need to register the target default custom job.

  To display the icons of standard custom jobs in the Jobnet Editor window and Jobnet Monitor window, you need to register the standard custom jobs in each host where JP1/AJS3 - View is installed.

  When JP1/AJS3 - View has just been installed, the Custom Jobs tab, which displays an icon list, does not appear in the Jobnet Editor window of JP1/AJS3 - View. To add a default custom job icon in the Custom Jobs page or display it in the map area in the Jobnet Editor window or the Jobnet Monitor window, you need to register the target default custom job in each host where JP1/AJS3 - View is installed. For details, see 3.2 Registering default custom jobs.

Icons for the following default custom jobs are provided with JP1/AJS3.

• For Windows

  JP1FTP, JP1AMR3, JP1AMR3BW, JP1AMR3CP, DHAJEW, and CPALINK

• For UNIX

  JP1FTP, JP1AMR3, JP1AMR3BW, JP1AMR3CP, JP1AMR3UX, JP1AMR3BWUX, and JP1AMR3CPUX

To obtain the icon for any other job, copy it from the linked program.
