3.15.1 Performance monitoring function by JP1/IM - Agent

windows_cache_copy_read_hits_total

cache

Number of copy read requests that hit the cache (cumulative)

instance: Instance identification string

job: Job name

windows_cache_copy_reads_total

cache

Number of reads from the file system cache page (cumulative)

instance: Instance identification string

job: Job name

windows_cpu_time_total

cpu

Number of seconds of processor time spent per mode (cumulative)

instance: Instance identification string

job: Job name

core: coreid

mode: Mode^#

#

Contains one of the following:

• "dpc"

• "idle"

• "interrupt"

• "privileged"

• "user"

windows_cs_physical_memory_bytes

cs

Number of bytes of the physical memory capacity

instance: Instance identification string

job: Job name

windows_logical_disk_idle_seconds_total

logical_disk

Number of seconds that the disk was idle (cumulative)

instance: Instance identification string

job: Job name

volume: Volume name

windows_logical_disk_free_bytes

logical_disk

Number of bytes of unused disk space

instance: Instance identification string

job: Job name

volume: Volume name

windows_logical_disk_read_bytes_total

logical_disk

Number of bytes transferred from disk during the read operation (cumulative)

instance: Instance identification string

job: Job name

volume: Volume name

windows_logical_disk_read_seconds_total

logical_disk

Number of seconds that the disk was busy for read operations (cumulative)

instance: Instance identification string

job: Job name

volume: Volume name

windows_logical_disk_reads_total

logical_disk

Number of read operations to disk (cumulative)

instance: Instance identification string

job: Job name

volume: Volume name

windows_logical_disk_requests_queued

logical_disk

Number of requests queued on disk

instance: Instance identification string

job: Job name

volume: Volume name

windows_logical_disk_size_bytes

logical_disk

Disk space bytes

instance: Instance identification string

job: Job name

volume: Volume name

windows_logical_disk_write_bytes_total

logical_disk

Number of bytes transferred to disk during the write operation (cumulative)

instance: Instance identification string

job: Job name

volume: Volume name

windows_logical_disk_write_seconds_total

logical_disk

Number of seconds that the disk was busy for write operations (cumulative)

instance: Instance identification string

job: Job name

volume: Volume name

windows_logical_disk_writes_total

logical_disk

Number of disk write operations (cumulative)

instance: Instance identification string

job: Job name

volume: Volume name

windows_memory_available_bytes

memory

Number of bytes of unused space in physical memory

Note:

The total of zero, free, and standby (cached) areas allocated to a process or immediately available to the system.

instance: Instance identification string

job: Job name

windows_memory_cache_bytes

memory

Number of bytes of physical memory used for file system caching

instance: Instance identification string

job: Job name

windows_memory_cache_faults_total

memory

Number of page faults in the file system cache (cumulative)

instance: Instance identification string

job: Job name

windows_memory_page_faults_total

memory

Number of times a page fault occurred (cumulative)

instance: Instance identification string

job: Job name

windows_memory_pool_nonpaged_allocs_total

memory

Number of times a nonpageable physical memory region was allocated

instance: Instance identification string

job: Job name

windows_memory_pool_paged_allocs_total

memory

Number of times you allocated a pageable physical memory region

instance: Instance identification string

job: Job name

windows_memory_swap_page_operations_total

memory

Number of pages read from or written to disk to resolve hard page faults (cumulative)

instance: Instance identification string

job: Job name

windows_memory_swap_pages_read_total

memory

Number of pages read from disk to resolve hard page faults (cumulative)

instance: Instance identification string

job: Job name

windows_memory_swap_pages_written_total

memory

Number of pages written to disk to resolve hard page faults (cumulative)

instance: Instance identification string

job: Job name

windows_memory_system_cache_resident_bytes

memory

Number of active system file cache bytes in physical memory

instance: Instance identification string

job: Job name

windows_memory_transition_faults_total

memory

The number of page faults resolved by recovering pages that were in use by other processes sharing the page, pages that were on the modified pages list or standby list, or pages that were written to disk (cumulative)

instance: Instance identification string

job: Job name

windows_net_bytes_received_total

net

Number of bytes received by the interface (cumulative)

Note:

If the NIC name contains characters other than half-width alphanumeric characters, these characters are converted to underscores and set in the NIC label.

instance: Instance identification string

job: Job name

device: Network Device Name

windows_net_bytes_sent_total

net

Number of bytes sent from the interface (cumulative)

Note:

If the NIC name contains characters other than half-width alphanumeric characters, these characters are converted to underscores and set in the NIC label.

instance: Instance identification string

job: Job name

device: Network Device Name

windows_net_bytes_total

net

Number of bytes received and transmitted by the interface (cumulative)

Note:

If the NIC name contains characters other than half-width alphanumeric characters, these characters are converted to underscores and set in the NIC label.

instance: Instance identification string

job: Job name

device: Network Device Name

windows_net_packets_sent_total

net

Number of packets sent by the interface (cumulative)

Note:

If the NIC name contains characters other than half-width alphanumeric characters, these characters are converted to underscores and set in the NIC label.

instance: Instance identification string

job: Job name

device: Network Device Name

windows_net_packets_received_total

net

Number of packets received by the interface (cumulative)

Note:

If the NIC name contains characters other than half-width alphanumeric characters, these characters are converted to underscores and set in the NIC label.

instance: Instance identification string

job: Job name

device: Network Device Name

windows_system_context_switches_total

system

Number of context switches (cumulative)

instance: Instance identification string

job: Job name

device: Network Device Name

windows_system_processor_queue_length

system

Number of threads in the processor queue

instance: Instance identification string

job: Job name

device: Network Device Name

windows_system_system_calls_total

system

Number of times the process called the OS service routine (cumulative)

instance: Instance identification string

job: Job name

windows_process_start_time

process

Time of process start

instance: instance-identifier-string

job: job-name

process: process-name

process_id: process-ID

creating_process_id: creator-process-ID

windows_process_cpu_time_total

process

Returns elapsed time that all of the threads of this process used the processor to execute instructions by mode (privileged, user). An instruction is the basic unit of execution in a computer, a thread is the object that executes instructions, and a process is the object created when a program is run. Code executed to handle some hardware interrupts and trap conditions is included in this count.

instance: instance-identifier-string

job: job-name

process: process-name

process_id: process-ID

creating_process_id: creator-process-ID

mode: mode (privileged or user)

windows_process_io_bytes_total

process

Bytes issued to I/O operations in different modes (read, write, other). This property counts all I/O activity generated by the process to include file, network, and device I/Os. Read and write mode includes data operations; other mode includes those that do not involve data, such as control operations.

instance: instance-identifier-string

job: job-name

process: process-name

process_id: process-ID

creating_process_id: creator-process-ID

mode: mode (privileged or user)

windows_process_io_operations_total

process

I/O operations issued in different modes (read, write, other). This property counts all I/O activity generated by the process to include file, network, and device I/Os. Read and write mode includes data operations; other mode includes those that do not involve data, such as control operations.

instance: instance-identifier-string

job: job-name

process: process-name

process_id: process-ID

creating_process_id: creator-process-ID

mode: mode (read, write, or other)

windows_process_page_faults_total

process

Page faults by the threads executing in this process. A page fault occurs when a thread refers to a virtual memory page that is not in its working set in main memory. This can cause the page not to be fetched from disk if it is on the standby list and hence already in main memory, or if it is in use by another process with which the page is shared.

instance: instance-identifier-string

job: job-name

process: process-name

process_id: process-ID

creating_process_id: creator-process-ID

windows_process_page_file_bytes

process

Current number of bytes this process has used in the paging file(s). Paging files are used to store pages of memory used by the process that are not contained in other files. Paging files are shared by all processes, and lack of space in paging files can prevent other processes from allocating memory.

instance: instance-identifier-string

job: job-name

process: process-name

process_id: process-ID

creating_process_id: creator-process-ID

windows_process_pool_bytes

process

Pool Bytes is the last observed number of bytes in the paged or nonpaged pool. The nonpaged pool is an area of system memory (physical memory used by the operating system) for objects that cannot be written to disk, but must remain in physical memory as long as they are allocated. The paged pool is an area of system memory (physical memory used by the operating system) for objects that can be written to disk when they are not being used. Nonpaged pool bytes is calculated differently than paged pool bytes, so it might not equal the total of paged pool bytes.

instance: instance-identifier-string

job: job-name

process: process-name

process_id: process-ID

creating_process_id: creator-process-ID

pool: paged (pool paged) or nonpaged (pool non paged)

windows_process_priority_base

process

Current base priority of this process. Threads within a process can raise and lower their own base priority relative to the process base priority of the process.

instance: instance-identifier-string

job: job-name

process: process-name

process_id: process-ID

creating_process_id: creator-process-ID

windows_process_private_bytes

process

Current number of bytes this process has allocated that cannot be shared with other processes.

instance: instance-identifier-string

job: job-name

process: process-name

process_id: process-ID

creating_process_id: creator-process-ID

windows_process_virtual_bytes

process

Current size, in bytes, of the virtual address space that the process is using. Use of virtual address space does not necessarily imply corresponding use of either disk or main memory pages. Virtual space is finite and, by using too much, the process can limit its ability to load libraries.

instance: instance-identifier-string

job: job-name

process: process-name

process_id: process-ID

creating_process_id: creator-process-ID

windows_service_state

service

The state of the service (State)

instance: instance-identifier-string

job: job-name

name: service-name^#1

state: service-status^#2

#1

Uppercase letters are converted to lowercase.

#2

Contains one of the following:

• continue pending (pending continuation)

• pause pending (suspended)

• paused (paused)

• running (running)

• start pending (pending startup)

• stop pending (suspended)

• stopped (stopped)

• unknown (unknown)

node_boot_time_seconds

stat

Last boot time

Note:

Shown in UNIX time, including microseconds.

instance: Instance identification string

job: Job name

node_context_switches_total

stat

Number of times a context switch has been made (cumulative)

instance: Instance identification string

job: Job name

node_cpu_seconds_total

cpu

CPU seconds spent in each mode (cumulative)

instance: Instance identification string

job: Job name

cpu: cpuid

mode: Mode^#

#

Contains one of the following:

• user

• nice

• system

• idle

• iowait

• irq

• soft

• steal

node_disk_io_now

diskstats

Number of disk I/Os currently in progress

instance: Instance identification string

job: Job name

device: Device name

node_disk_io_time_seconds_total

diskstats

Seconds spent on disk I/O (cumulative)

instance: Instance identification string

job: Job name

device: Device name

node_disk_read_bytes_total

diskstats

Number of bytes successfully read from disk (cumulative)

instance: Instance identification string

job: Job name

device: Device name

node_disk_read_time_seconds_total

diskstats

Seconds took to read from disk (cumulative value)

instance: Instance identification string

job: Job name

device: Device name

node_disk_reads_completed_total

diskstats

Number of successfully completed reads from disk (cumulative)

instance: Instance identification string

job: Job name

device: Device name

node_disk_write_time_seconds_total

diskstats

Seconds took to write to disk (cumulative value)

instance: Instance identification string

job: Job name

device: Device name

node_disk_writes_completed_total

diskstats

Number of successfully completed disk writes (cumulative)

instance: Instance identification string

job: Job name

device: Device name

node_disk_written_bytes_total

diskstats

Number of bytes successfully written to disk (cumulative)

instance: Instance identification string

job: Job name

device: Device name

node_filesystem_avail_bytes

filesystem

Number of file system bytes available to non-root users

instance: Instance identification string

job: Job name

fstype: File System Type

mountpoint: Mount Point

node_filesystem_files

filesystem

Number of file nodes in the file system

instance: Instance identification string

job: Job name

fstype: File System Type

mountpoint: Mount Point

node_filesystem_files_free

filesystem

Number of free file nodes in the file system

instance: Instance identification string

job: Job name

fstype: File System Type

mountpoint: Mount Point

node_filesystem_free_bytes

filesystem

Number of bytes of free file system space

instance: Instance identification string

job: Job name

fstype: File System Type

mountpoint: Mount Point

node_filesystem_size_bytes

filesystem

Number of bytes in file system capacity

instance: Instance identification string

job: Job name

fstype: File System Type

mountpoint: Mount Point

node_intr_total

stat

Number of interrupts handled (cumulative)

instance: Instance identification string

job: Job name

node_load1

loadavg

One-minute average of the number of jobs in the run queue

instance: Instance identification string

job: Job name

node_load15

loadavg

15-minute average of the number of jobs in the run queue

instance: Instance identification string

job: Job name

node_load5

loadavg

5-minute average of the number of jobs in the run queue

instance: Instance identification string

job: Job name

node_memory_Active_file_bytes

meminfo

Bytes of recently used file cache memory

Note:

The value obtained by converting the Active(file) of /proc/meminfo to bytes.

instance: Instance identification string

job: Job name

node_memory_Buffers_bytes

meminfo

Number of bytes in the file buffer

Note:

The value of Buffers converted to bytes in /proc/meminfo.

instance: Instance identification string

job: Job name

node_memory_Cached_bytes

meminfo

Number of bytes in file read cache memory

Note:

This is the value of Cached converted to bytes in /proc/meminfo.

instance: Instance identification string

job: Job name

node_memory_Inactive_file_bytes

meminfo

Number of bytes of file cache memory that have not been used recently

Note:

The value of the Inactive(file) of /proc/meminfo converted to bytes.

instance: Instance identification string

job: Job name

node_memory_MemAvailable_bytes

meminfo

The number of bytes of memory available to start a new application without swapping

Note:

The value of MemAvailable in /proc/meminfo converted to bytes.

instance: Instance identification string

job: Job name

node_memory_MemFree_bytes

meminfo

Number of bytes of free memory

Note:

The value of MemFree in /proc/meminfo converted to bytes.

instance: Instance identification string

job: Job name

node_memory_MemTotal_bytes

meminfo

Total amount of bytes of memory

Note:

The value of MemTotal converted to bytes in /proc/meminfo.

instance: Instance identification string

job: Job name

node_memory_SReclaimable_bytes

meminfo

Number of bytes in the Slab cache that can be reclaimed

Note:

SReclaimable in /proc/meminfo converted to bytes.

instance: Instance identification string

job: Job name

node_memory_SwapFree_bytes

meminfo

Number of bytes of free swap memory space

Note:

The value of SwapFree in /proc/meminfo converted to bytes.

instance: Instance identification string

job: Job name

node_memory_SwapTotal_bytes

meminfo

Bytes of total swap memory

Note:

This is the value of SwapTotal converted to bytes in /proc/meminfo.

instance: Instance identification string

job: Job name

node_netstat_Icmp6_InMsgs

netstat

Number of ICMPv6 messages received (cumulative)

instance: Instance identification string

job: Job name

device: Network Device Name

node_netstat_Icmp_InMsgs

netstat

Number of ICMPv4 messages received (cumulative)

instance: Instance identification string

job: Job name

device: Network Device Name

node_netstat_Icmp6_OutMsgs

netstat

Number of ICMPv6 messages sent (cumulative)

instance: Instance identification string

job: Job name

device: Network Device Name

node_netstat_Icmp_OutMsgs

netstat

Number of ICMPv4 messages sent (cumulative)

instance: Instance identification string

job: Job name

device: Network Device Name

node_netstat_Tcp_InSegs

netstat

Number of TCP packets received (cumulative)

instance: Instance identification string

job: Job name

device: Network Device Name

node_netstat_Tcp_OutSegs

netstat

Number of TCP packets sent (cumulative)

instance: Instance identification string

job: Job name

device: Network Device Name

node_netstat_Udp_InDatagrams

netstat

Number of UDP packets received (cumulative)

instance: Instance identification string

job: Job name

device: Network Device Name

node_netstat_Udp_OutDatagrams

netstat

Number of UDP packets sent (cumulative)

instance: Instance identification string

job: Job name

device: Network Device Name

node_network_flags

netclass

A numeric value indicating the state of the interface

Note:

/sys/class/net/[iface]/flags is a decimal value.

instance: Instance identification string

job: Job name

device: Network Device Name

node_network_iface_link

netclass

Interface serial number

Note:

The value of /sys/class/net/[iface]/iflink.

instance: Instance identification string

job: Job name

device: Network Device Name

node_network_mtu_bytes

netclass

Interface MTU value

Note:

The value of /sys/class/net/[iface]/mtu.

instance: Instance identification string

job: Job name

device: Network Device Name

node_network_receive_bytes_total

netdev

Number of bytes received by the network device (cumulative value)

instance: Instance identification string

job: Job name

device: Network Device Name

node_network_receive_errs_total

netdev

Number of network device receive errors (cumulative)

instance: Instance identification string

job: Job name

device: Network Device Name

node_network_receive_packets_total

netdev

Number of packets received by network devices (cumulative)

instance: Instance identification string

job: Job name

device: Network Device Name

node_network_transmit_bytes_total

netdev

Number of bytes sent by the network device (cumulative value)

instance: Instance identification string

job: Job name

device: Network Device Name

node_network_transmit_colls_total

netdev

Number of transmit collisions for network devices (cumulative)

instance: Instance identification string

job: Job name

device: Network Device Name

node_network_transmit_errs_total

netdev

Number of transmission errors for network devices (cumulative)

instance: Instance identification string

job: Job name

device: Network Device Name

node_network_transmit_packets_total

netdev

Number of packets sent by network devices (cumulative)

instance: Instance identification string

job: Job name

device: Network Device Name

node_time_seconds

time

Seconds of system time since the epoch (1970)

instance: Instance identification string

job: Job name

node_uname_info

uname

System information obtained by the uname system call

instance: Instance identification string

job: Job name

domainname: NIS and YP domain names

machine: Hardware Identifiers

nodename: Machine name in some network defined at implementation time

release: Operating system release number (e.g. "2.6.28")

sysname: The name of the OS (e.g. "Linux")

version: Operating system version

node_vmstat_pswpin

vmstat

Number of page swap-ins (cumulative)

Note:

The value of the pswpin in /proc/vmstat.

instance: Instance identification string

job: Job name

node_vmstat_pswpout

vmstat

Number of page swap-outs (cumulative)

Note:

The value of pswpout in /proc/vmstat.

instance: Instance identification string

job: Job name

node_systemd_unit_state

systemd

The state of the systemd unit.

instance: instance-identifier-string

job: job-name

name: unit-file-name

state: service-status^#1

type: How to launch a process^#2

#1

Contains one of the following:

• activating (during startup)

• active (running)

• deactivating (stopped)

• failed (failed to execute)

• inactive (stopped)

#2

Contains the Type value of the unit file.

namedprocess_namegroup_num_procs

Number of processes in this group.

instance: instance-identifier-string

job: job-name

groupname: group-name

namedprocess_namegroup_cpu_seconds_total

CPU usage based on /proc/[pid]/stat fields utime(14) and stime(15) i.e. user and system time.

instance: instance-identifier-string

job: job-name

groupname: group-name

mode: user or system

namedprocess_namegroup_read_bytes_total

Bytes read based on /proc/[pid]/io field read_bytes. As /proc/[pid]/io are set by the kernel as read only to the process' user, to get these values you should run process-exporter either as that user or as root. Otherwise, we can't read these values and you'll get a constant 0 in the metric.

instance: instance-identifier-string

job: job-name

groupname: group-name

namedprocess_namegroup_write_bytes_total

Bytes written based on /proc/[pid]/io field write_bytes.

instance: instance-identifier-string

job: job-name

groupname: group-name

namedprocess_namegroup_major_page_faults_total

Number of major page faults based on /proc/[pid]/stat field majflt(12).

instance: instance-identifier-string

job: job-name

groupname: group-name

namedprocess_namegroup_minor_page_faults_total

Number of minor page faults based on /proc/[pid]/stat field minflt(10).

instance: instance-identifier-string

job: job-name

groupname: group-name

namedprocess_namegroup_context_switches_total

Number of context switches based on /proc/[pid]/status fields voluntary_ctxt_switches and nonvoluntary_ctxt_switches. The extra label ctxswitchtype can have two values: voluntary and nonvoluntary.

instance: instance-identifier-string

job: job-name

groupname: group-name

ctxswitchtype: voluntary or nonvoluntary

namedprocess_namegroup_memory_bytes

Number of bytes of memory used. The extra label memtype can have three values:

• resident: Field rss(24) from /proc/[pid]/stat. This is just the pages which count toward text, data, or stack space. This does not include pages which have not been demand-loaded in, or which are swapped out.

• virtual: Field vsize(23) from /proc/[pid]/stat, virtual memory size.

• swapped: Field VmSwap from /proc/[pid]/status, translated from KB to bytes.

If gathering smaps file is enabled, two additional values for memtype are added:

• proportionalResident: Sum of Pss fields from /proc/[pid]/smaps

proportionalSwapped: Sum of SwapPss fields from /proc/[pid]/smaps

instance: instance-identifier-string

job: job-name

groupname: group-name

memtype: resident, virtual, swapped, proportionalResident, or proportionalSwapped

namedprocess_namegroup_open_filedesc

Number of file descriptors, based on counting how many entries are in the directory /proc/[pid]/fd.

instance: instance-identifier-string

job: job-name

groupname: group-name

namedprocess_namegroup_worst_fd_ratio

Worst ratio of open filedescs to filedesc limit, amongst all the procs in the group. The limit is the fd soft limit based on /proc/[pid]/limits.

instance: instance-identifier-string

job: job-name

groupname: group-name

namedprocess_namegroup_oldest_start_time_seconds

Epoch time (seconds since 1970/1/1) at which the oldest process in the group started. This is derived from field starttime(22) from /proc/[pid]/stat, added to boot time to make it relative to epoch.

instance: instance-identifier-string

job: job-name

groupname: group-name

namedprocess_namegroup_num_threads

Sum of number of threads of all process in the group. Based on field num_threads(20) from /proc/[pid]/stat.

instance: instance-identifier-string

job: job-name

groupname: group-name

namedprocess_namegroup_states

Number of threads in the group in each of various states, based on the field state(3) from /proc/[pid]/stat.

The extra label state can have these values: Running, Sleeping, Waiting, Zombie, Other.

instance: instance-identifier-string

job: job-name

groupname: group-name

state: Running, Sleeping, Waiting, Zombie, or Other

namedprocess_namegroup_thread_count

Number of threads in this thread subgroup.

instance: instance-identifier-string

job: job-name

groupname: group-name

threadname: thread-name

namedprocess_namegroup_thread_cpu_seconds_total

Same as cpu_user_seconds_total and cpu_system_seconds_total, but broken down per-thread subgroup.

instance: instance-identifier-string

job: job-name

groupname: group-name

threadname: thread-name

mode: user or system

namedprocess_namegroup_thread_io_bytes_total

Same as read_bytes_total and write_bytes_total, but broken down per-thread subgroup. Unlike read_bytes_total/write_bytes_total, the label iomode is used to distinguish between read and write bytes.

instance: instance-identifier-string

job: job-name

groupname: group-name

threadname: thread-name

iomode: read or write

namedprocess_namegroup_thread_major_page_faults_total

Same as major_page_faults_total, but broken down per-thread subgroup.

instance: instance-identifier-string

job: job-name

groupname: group-name

namedprocess_namegroup_thread_minor_page_faults_total

Same as minor_page_faults_total, but broken down per-thread subgroup.

instance: instance-identifier-string

job: job-name

groupname: group-name

namedprocess_namegroup_thread_context_switches_total

Same as context_switches_total, but broken down per-thread subgroup.

instance: instance-identifier-string

job: job-name

groupname: group-name

node_context_switches

-C

Total number of context switches.

(cumulative value)

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

Get by perfstat_cpu_total func

pswitch of perfstat_cpu_t structure

node_cpu

-C

Seconds the cpus spent in each mode.

(cumulative value)

instance: instance-identity-string

job: job-name

cpu: cpuid

mode: mode (idle, sys, user, or wait)

Get by perfstat_cpu func

Perfstat_cpu_t structure

aix_diskpath_wblks

-D

Blocks written via the path

cpupool_id=physical-processor-shared-pooling-ID

diskpath=disk pathname

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

Get by perfstat_diskpath func

wblks of perfstat_diskpath_t structure

aix_diskpath_rblks

-D

Blocks read via the path

cpupool_id=physical-processor-shared-pooling-ID

diskpath=disk-path-name

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

Get by perfstat_diskpath func

rblks of perfstat_diskpath_t structure

aix_disk_rserv

-d

Read or receive service time

cpupool_id=physical-processor-shared-pooling-ID

disk=disk-name

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

vgname=volume-group-name

Get by perfstat_disk func

rserv of perfstat_disk_t structure

aix_disk_rblks

-d

Number of blocks read from disk

cpupool_id=physical-processor-shared-pooling-ID

disk=disk-name

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

vgname=volume-group-name

Get by perfstat_disk func

rblks of perfstat_disk_t structures

aix_disk_wserv

-d

Write or send service time

cpupool_id=physical-processor-shared-pooling-ID

disk=disk-name

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

vgname=volume-group-name

Get by perfstat_disk func

wserv of perfstat_disk_t structure

aix_disk_wblks

-d

Number of blocks written to disk

cpupool_id=physical-processor-shared-pooling-ID

disk=disk-name

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

vgname=volume-group-name

Get by perfstat_disk func

wblks of perfstat_disk_t structure

aix_disk_time

-d

Amount of time disk is active

cpupool_id=physical-processor-shared-pooling-ID

disk=disk-name

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

vgname=volume-group-name

Get by perfstat_disk func

time of perfstat_disk_t structure

aix_disk_xrate

-d

Number of transfers from disk

cpupool_id=physical-processor-shared-pooling-ID

disk=disk-name

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

vgname=volume-group-name

Get by perfstat_disk func

xrate of perfstat_disk_t structure

aix_disk_xfers

-d

Number of transfers to/from disk

cpupool_id=physical-processor-shared-pooling-ID

disk=disk-name

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

vgname=volume-group-name

Get by perfstat_disk func

xfers of perfstat_disk_t structure

node_filesystem_avail_bytes

-f

Filesystem space available to non-root users in bytes.

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

device=device-name

fstype=file-system-type

mountpoint=mount-point

Get by stat_filesystems func

avail_bytes of filesystem structure

node_filesystem_files

-f

Filesystem total file nodes.

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

device=device-name

fstype=file-system-type

mountpoint=mount-point

Get by stat_filesystems func

files of filesystem structure

node_filesystem_files_free

-f

Filesystem total free file nodes.

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

device=device-name

fstype=file-system-type

mountpoint=mount-point

Get by stat_filesystems func

files_free of filesystem structure

node_filesystem_free_bytes

-f

Filesystem free space in bytes.

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

device=device-name

fstype=file-system-type

mountpoint=mount-point

Get by stat_filesystems func

free_bytes of filesystem structure

node_filesystem_size_bytes

-f

Filesystem size in bytes.

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

device=device-name

fstype=file-system-type

mountpoint=mount-point

Get by stat_filesystems func

size_bytes of filesystem structure

node_intr

-C

Total number of interrupts serviced.

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

Get by perfstat_cpu_total func

decrintrs of perfstat_cpu_total_t structure

mpcsintrs of perfstat_cpu_total_t structure

devintrs of perfstat_cpu_total_t structure

softintrs of perfstat_cpu_total_t structure

node_load1

-C

1m load average.

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

Get by perfstat_cpu_total func

loadavg[0] of perfstat_cpu_total_t structure

node_load5

-C

5m load average.

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

Get by perfstat_cpu_total func

loadavg[1] of perfstat_cpu_total_t structure

node_load15

-C

15m load average.

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

Get by perfstat_cpu_total func

loadavg[2] of perfstat_cpu_total_t structure

aix_memory_real_avail

-m

Number of pages (in 4KB pages) of memory available without paging out working segments

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

Get by perfstat_memory_total func

real_avail of perfstat_memory_total_t structure

aix_memory_real_free

-m

Free real memory (in 4 KB pages).

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

Get by perfstat_memory_total func

real_free of perfstat_memory_total_t structures

aix_memory_real_inuse

-m

Real memory which is in use (in 4KB pages)

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

Get by perfstat_memory_total func

real_inuse of perfstat_memory_total_t structures

aix_memory_real_total

-m

Total real memory (in 4 KB pages).

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

Get by perfstat_memory_total func

perfstat_memory_total_t structure real_total

aix_netinterface_mtu

-i

Network frame size

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

netinterface=net interface name

Get by perfstat_netinterface func

mtu of perfstat_netinterface_t structure

aix_netinterface_ibytes

-i

Number of bytes received on interface

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

netinterface=net interface name

Get by perfstat_netinterface func

ibytes of perfstat_netinterface_t structure

aix_netinterface_ierrors

-i

Number of input errors on interface

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

netinterface=net interface name

Get by perfstat_netinterface func

ierrors of perfstat_netinterface_t structure

aix_netinterface_ipackets

-i

Number of packets received on interface

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

netinterface=net interface name

Get by perfstat_netinterface func

ipackets of perfstat_netinterface_t structure

aix_netinterface_obytes

-i

Number of bytes sent on interface

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

netinterface=net interface name

Get by perfstat_netinterface func

obytes of perfstat_netinterface_t structure

aix_netinterface_collisions

-i

Number of collisions on csma interface

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

netinterface=net interface name

Get by perfstat_netinterface func

collisions of perfstat_netinterface_t structure

aix_netinterface_oerrors

-i

Number of output errors on interface

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

netinterface=net interface name

Get by perfstat_netinterface func

oerrors of perfstat_netinterface_t structure

aix_netinterface_opackets

-i

Number of packets sent on interface

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

netinterface=net interface name

Get by perfstat_netinterface func

opackets of perfstat_netinterface_t structure

aix_memory_pgspins

-m

Number of page ins from paging space

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

Get by perfstat_memory_total func

pgspins of perfstat_memory_total_t structure

aix_memory_pgspouts

-m

Number of pages paged out from paging space

cpupool_id=physical-processor-shared-pooling-ID

group_id=group-ID

instance: instance-identity-string

job: job-name

lpar=partition-name

machine_serial=machine-ID

Get by perfstat_memory_total func

pgspouts of perfstat_memory_total_t structure

discovery:

exportedTagsOnMetrics:

ec2:

- jp1_pc_nodelabel

jobs:

- type: ec2

regions:

- ap-northeast-1

period: 60

length: 300

delay: 60

nilToZero: true

searchTags:

- key: jp1_pc_nodelabel

value: .*

metrics:

- name: CPUUtilization

statistics:

- Maximum

- name: DiskReadBytes

statistics:

- Maximum

VirtualMachine

Microsoft.Compute/virtualMachines

Y

FunctionApp

Microsoft.Web/sites

Y

ContainerInstance

Microsoft.ContainerInstance/containerGroups

--

KubernetesService

Microsoft.ContainerService/managedClusters

Y

FileStorage

Microsoft.Storage/storageAccounts/fileServices

--

BlobStorage

Microsoft.Storage/storageAccounts/blobServices

--

ServiceBusNamespace

Microsoft.ServiceBus/namespaces

Y

CosmosDb

Microsoft.DocumentDB/databaseAccounts

Y

SqlDatabase

Microsoft.Sql/servers/databases

Y

SqlServer

Microsoft.Sql/servers/databases

Microsoft.Sql/servers/elasticPools

--

SqlManagedInstance

Microsoft.Sql/managedInstances

Y

SqlElasticPool

Microsoft.Sql/servers/elasticPools

Y

LogicApp

Microsoft.Logic/workflows

Y

probe_http_duration_seconds

http

The number of seconds taken per phase of the HTTP request

Note:

All redirects add up.

instance: Instance identification string

job: Job name

phase: Phase^#

#

Contains one of the following:

• "resolve"

• "connect"

• "tls"

• "processing"

• "transfer"

probe_http_content_length

http

HTTP content response length

instance: Instance identification string

job: Job name

probe_http_uncompressed_body_length

http

Uncompressed response body length

instance: Instance identification string

job: Job name

probe_http_redirects

http

Number of redirects

instance: Instance identification string

job: Job name

probe_http_ssl

http

Whether SSL was used for the final redirect

• 0: TLS/SSL was not used

• 1: TLS/SSL was used

instance: Instance identification string

job: Job name

probe_http_status_code

http

HTTP response status code value

Note:

If you are redirecting, the final status code is the value of the metric.

If no redirection is performed, the first status code received is the value of the metric.

instance: Instance identification string

job: Job name

probe_ssl_earliest_cert_expiry

http

Earliest expiring SSL certificate UNIX time

instance: Instance identification string

job: Job name

probe_ssl_last_chain_expiry_timestamp_seconds

http

Expiration timestamp of the last certificate in the SSL chain

Note:

If you want to monitor this metric, you must specify false for the insecure_skip_verify parameter in the tls_config settings of the Blackbox exporter configuration file (jpc_blackbox_exporter.yml), place the certificate, and specify the path of the certificate file in the appropriate parameter.

instance: Instance identification string

job: Job name

probe_ssl_last_chain_info

http

SSL leaf certificate information

Note:

This is the SHA256 hash value of the server certificate to be monitored. The hash value is set to the label "fingerprint_sha256".

instance: Instance identification string

job: Job name

fingerprint_sha256: SHA256 fingerprint on certificate

probe_tls_version_info

http

TLS version used

Note:

The TLS version, such as "TLS 1.2", is set to the label "version".

instance: Instance identification string

job: Job name

version:TLS Version

probe_http_version

http

HTTP version of the probe response

instance: Instance identification string

job: Job name

probe_failed_due_to_regex

http

Whether the probe failed due to a regular expression check on the response body or response headers

• 0: Success

• 1: Failed

instance: Instance identification string

job: Job name

probe_http_last_modified_timestamp_seconds

http

UNIX time showing Last-Modified HTTP response headers

instance: Instance identification string

job: Job name

probe_icmp_duration_seconds

icmp

Seconds taken per phase of an ICMP request

instance: Instance identification string

job: Job name

phase: Phase^#

#

Contains one of the following:

• resolve

  Name Resolution Time

• setup

  Time from resolve completion to ICMP packet transmission

• rtt

  Time to get a response after setup

probe_icmp_reply_hop_limit

icmp

Hop limit (TTL for IPv4) value

Note:

Hop limit (TTL for IPv4) value

instance Instance identification string

job: Job name

probe_success

--

Whether the probe was successful

• 0: Failed

• 1: Success

instance Instance identification string

job: Job name

probe_duration_seconds

--

The number of seconds it took for the probe to complete

instance Instance identification string

job: Job name

CA certificate file

A file encoding an X509 public key certificate in pkcs7 format in PEM format

Client certificate file

Client certificate key file

A file in which the private key in pkcs1 or pkcs8 format is encoded in PEM format^#

#

You cannot use password-protected files.

TLS Version

1.2 to 1.3

Cipher suites

• "TLS_RSA_WITH_AES_128_CBC_SHA" (up to TLS 1.2)

• "TLS_RSA_WITH_AES_256_CBC_SHA" (up to TLS 1.2)

• "TLS_RSA_WITH_AES_128_GCM_SHA256" (TLS 1.2 only)

• "TLS_RSA_WITH_AES_256_GCM_SHA384" (TLS 1.2 only)

• "TLS_AES_128_GCM_SHA256" (TLS 1.3 only)

• "TLS_AES_256_GCM_SHA384" (TLS 1.3 only)

• "TLS_CHACHA20_POLY1305_SHA256" (TLS 1.3 only)

• "TLS_ECDHE_ECDSA_WITH_AES_128_CBC_SHA" (up to TLS 1.2)

• "TLS_ECDHE_ECDSA_WITH_AES_256_CBC_SHA" (up to TLS 1.2)

• "TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA" (up to TLS 1.2)

• "TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA" (up to TLS 1.2)

• "TLS_ECDHE_ECDSA_WITH_AES_128_GCM_SHA256" (TLS 1.2 only)

• "TLS_ECDHE_ECDSA_WITH_AES_256_GCM_SHA384" (TLS 1.2 only)

• "TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256" (TLS 1.2 only)

• "TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384" (TLS 1.2 only)

• "TLS_ECDHE_RSA_WITH_CHACHA20_POLY1305_SHA256" (TLS 1.2 only)

• "TLS_ECDHE_ECDSA_WITH_CHACHA20_POLY1305_SHA256" (TLS 1.2 only)

script_success

Script exit status (0 = error, 1 = success)

instance: instance-identifier-string

job: job-name

script: script-name

script_duration_seconds

Script execution time, in seconds.

instance: instance-identifier-string

job: job-name

script: script-name

script_exit_code

The exit code of the script.

instance: instance-identifier-string

job: job-name

script: script-name

oracledb_sessions_value

Count of sessions

status: status

type: session type

SELECT status, type, COUNT(*) as value FROM v$session GROUP BY status, type

oracledb_resource_current_utilization

Resource usage^#1

resource_name: resource_name

SELECT resource_name,current_utilization,CASE WHEN TRIM(limit_value) LIKE 'UNLIMITED' THEN '-1' ELSE TRIM(limit_value) END as limit_value FROM v$resource_limit

oracledb_resource_limit_value

Resource usage limit^#1 (UNLIMITED: -1)

resource_name: resource_name

oracledb_asm_diskgroup_total

Bytes of total size of ASM disk group

name: disk group name

SELECT name,total_mb*1024*1024 as total,free_mb*1024*1024 as free FROM v$asm_diskgroup_stat where exists (select 1 from v$datafile where name like '+%')

oracledb_asm_diskgroup_free

Bytes of free space available on ASM disk group

name: disk group name

oracledb_activity_execute_count

Total number of calls (user calls and recursive calls) executing SQL statements (cumulative value)

none

SELECT name, value FROM v$sysstat WHERE name IN ('parse count (total)', 'execute count', 'user commits', 'user rollbacks', 'db block gets from cache', 'consistent gets from cache', 'physical reads cache')

oracledb_activity_parse_count_total

Total number of parse calls (hard, soft and describe) (cumulative value)

none

oracledb_activity_user_commits

Total number of user commit (cumulative value)

none

oracledb_activity_user_rollbacks

The number of times a user manually issued a ROLLBACK statement, or the total number of times an error occurred during a user's transaction (cumulative value)

none

oracledb_activity_physical_reads_cache

Total number of data blocks read from disk to the buffer cache (cumulative value)

none

oracledb_activity_consistent_gets_from_cache

Number of times block read consistency was requested from the buffer cache (cumulative value)

none

oracledb_activity_db_block_gets_from_cache

Number of times CURRENT blocking was requested from the buffer cache (cumulative value)

none

oracledb_process_count

Count of Oracle Database active-processes

none

SELECT COUNT(*) as count FROM v$process

oracledb_wait_time_administrative

Hours spent waiting for Administrative wait class (in 1/100 seconds)^#2

none

SELECT

n.wait_class as WAIT_CLASS,

round(m.time_waited/m.INTSIZE_CSEC,3) as VALUE

FROM

v$waitclassmetric m, v$system_wait_class n

WHERE

m.wait_class_id=n.wait_class_id AND n.wait_class != 'Idle'

oracledb_wait_time_application

Hours spent waiting for Application wait class (in 1/100 seconds)^#2

none

oracledb_wait_time_commit

Hours spent waiting for Commit wait class (in 1/100 seconds)^#2

none

oracledb_wait_time_concurrency

Hours spent waiting for Concurrency wait class (in 1/100 seconds)^#2

none

oracledb_wait_time_configuration

Hours spent waiting for Configuration wait class (in 1/100 seconds)^#2

none

oracledb_wait_time_network

Hours spent waiting for Network wait class (in 1/100 seconds)^#2

none

oracledb_wait_time_other

Hours spent waiting for Other wait class (in 1/100 seconds)^#2

none

oracledb_wait_time_scheduler

Hours spent waiting for Scheduler wait class (in 1/100 seconds)^#2

none

oracledb_wait_time_system_io

Hours spent waiting for System I/O wait class (in 1/100 seconds)^#2

none

oracledb_wait_time_user_io

Hours spent waiting for User I/O wait class (in 1/100 seconds)^#2

none

oracledb_tablespace_bytes

Total bytes consumed by tablespaces

tablespace: name of the tablespace

type: tablespace contents

SELECT

dt.tablespace_name as tablespace,

dt.contents as type,

dt.block_size * dtum.used_space as bytes,

dt.block_size * dtum.tablespace_size as max_bytes,

dt.block_size * (dtum.tablespace_size - dtum.used_space) as free,

dtum.used_percent

FROM dba_tablespace_usage_metrics dtum, dba_tablespaces dt

WHERE dtum.tablespace_name = dt.tablespace_name

ORDER by tablespace

oracledb_tablespace_max_bytes

Maximum number of bytes in a tablespace

tablespace: name of the tablespace

type: tablespace contents

oracledb_tablespace_free

Number of free bytes in the tablespace

tablespace: name of the tablespace

type: tablespace contents

oracledb_tablespace_used_percent

Tablespace utilization

If auto extension is ON, it is calculated with auto extension taken into account.

tablespace: name of the tablespace

type: tablespace contents

oracledb_exporter_last_scrape_duration_seconds

The number of seconds taken the last scrape

none

-

oracledb_exporter_last_scrape_error

Whether the last scrape resulted in an error

0: Error

1: Success

none

-

oracledb_exporter_scrapes_total

Total number of times Oracle Database was scraped for metrics

none

-

oracledb_up

Whether the Oracle Database Server is up

0: Not running

1: Running

none

-

$ORACLE_BASE/diag/rdbms

.trc, .trm

Windows

forfiles /P "%ORACLE_BASE%\diag\rdbms" /M *.trm /S /C "cmd /C del /Q @path" /D -14

forfiles /P "%ORACLE_BASE%\diag\rdbms" /M *.trc /S /C "cmd /C del /Q @path" /D -14

Linux

find $ORACLE_BASE/diag/rdbms -name '*.tr[cm]' -mtime +14 -delete

name

Configure any unique alert group definition name in integrated agent.

Alert group definition name

alert

Set any unique alert-definition-name in integrated agent.

Alert Definition Name

expr

Set the PromQL statement.

It is recommended to set the PromQL statement described in the metric definition file. This way, when the JP1 event occurs, you can display trend information in the Integrated Operation Viewer.

Firing conditions^#

#

If the conditions are met, it is firing, and if the conditions are not met, it is resolved.

labels.jp1_pc_product_name

Set "/HITACHI/JP1/JPCCS" as fixed.

Set to the product name of the JP1 event.

labels.jp1_pc_severity

Set one of the following:

• Emergency

• Alert

• Critical

• Error

• Warning

• Notice

• Information

• Debug

Set to JP1 event severity^#.

#

This value is set to the severity of the JP1 event of the anomaly. The severity of a successful JP1 event is set to Information.

labels.jp1_pc_eventid

Set any value in the range of 0~1FFF,7FFF8000~7FFFFFFF.

Set to the event ID of the JP1 event.

labels.jp1_pc_metricname

Set the metric name.

For Yet another cloudwatch exporter, be sure to specify it. Associates the JP1 event with the IM management node in the AWS namespace corresponding to the metric name (or the first metric name if multiple metric names are specified separated by commas).

Set to the metric name of the JP1 event.

For yet another cloudwatch exporter, it is also used to correlate JP1 events.

annotations.jp1_pc_firing_description

Specify the value to be set for the message of the JP1 event when the firing condition of the alert is satisfied.

If the length of the value is 1,024 bytes or more, set the string from the beginning to the 1,023rd byte.

If the specification is omitted, the message content of the JP1 event is "The alert is firing. (alert = alert name)".

You can also specify variables to embed job names and evaluation values. If a variable is used, the first 1,024 bytes of the expanded message are valid.

It is set to the message of the JP1 event.

annotations.jp1_pc_resolved_description

Specify the value to be set for the message of the JP1 event when the firing condition of the alert is not satisfied.

If the length of the value is 1,024 bytes or more, set the string from the beginning to the 1,023rd byte.

If the specification is omitted, the content of the message in the JP1 event is "The alert is resolved. (alert = alert name)".

You can also specify variables to embed job names and evaluation values. If a variable is used, the first 1,024 bytes of the expanded message are valid.

It is set to the message of the JP1 event.
