F.1 Example of operation

If a failure occurs in the primary node and HACMP for AIX determines that a failover to another node is needed, HACMP for AIX stops the primary system and starts services on the standby system to continue. The shared disk will be mounted onto the standby system. The following figure shows an example of multiple node operation.
