7.5.4 Displaying profiles
Using IM Configuration Management, you can display JP1/Base profiles of agents and profiles of remotely monitored hosts in the Display/Edit Profiles window.
The figure below shows the flow of processing when displaying profiles with IM Configuration Management.
|
|
![[Figure]](GRAPHICS/CF072500.GIF)
- Organization of this subsection
(1) Profile information that can be displayed for agents according to the status of service activity
The following table describes the profile information you can display according to whether the service is active or inactive.
|
Profile type |
Service activity status |
Display of valid configuration information |
Display of configuration file contents |
|---|---|---|---|
|
Event Forwarding |
Running |
Y |
Y |
|
Stopped |
N |
Y |
|
|
Log File Trapping |
Running |
Y |
Y |
|
Stopped |
N |
Y |
|
|
Event Log Trapping |
Running |
Y |
Y |
|
Stopped |
N |
Y |
|
|
Local Action |
Running |
Y |
Y |
|
Inactive |
N |
Y |
|
|
Stopped |
N |
Y |
- Legend:
-
Y: Can be displayed.
N: Cannot be displayed.
(2) Profile information that can be displayed for remotely monitored hosts according to the status of service activity
The following profile information can be displayed:
-
Remote-monitoring log file trap information
-
Remote-monitoring event log trap information (for Windows only)
