11.5.13 Example of executing a user report
This subsection describes how to execute, by window operation and from the command line, the user report created in 11.5.12 Example of creating a user report.
- Organization of this subsection
(1) Example of execution by window operation
Under Device Management, select the List of Address in Use job menu to display the created user report window.
The figure below shows the created user report window.
|
If you specify a search condition and then click the Search button, the list of IP addresses in use is displayed. As the search result, this example displays the devices that are using the IP addresses from 10.XXX.XX.200 to 10.XXX.XX.210 in Section 1.
In the search results, clicking a column title sorts the list in ascending or descending order of the data in that column.
- Downloading the search results
-
By clicking the CSV button, you can download to a CSV file the information displayed as the search results.
- Outputting the search results
-
By clicking the PDF button, you can output the information displayed in the Search result list to a form in PDF format. To do so, linkage with EUR is required. For details about how to link with EUR, see 7.3 Setting up the asset management server.
- Displaying and editing details
-
Clicking an Asset No. link displays the Device Details dialog box that enables you to view and edit details about that device.
(2) Example of execution from the command line
In this example, a user with administrator permissions searches the List of Address in Use user report from a command line, and outputs the results to C:\Machine.csv.
-
When no search condition is specified
jamUserReport -n "List of Address in Use" -pf "C:\Machine.csv"
-
When groups and an IP address range 10.XXX.XX.200 to 10.XXX.XX.210 are specified as search conditions
jamUserReport -n "List of Address in Use" -cv "Group=Head Office/Sales Dept./Section 1" -cv "StartIPAddress=10.XXX.XX.200" -cv "EndIPAddress=10.XXX.XX.210" -pf "C:\Machine.csv"
