2.6.3 Updating an instance environment

To update an instance environment, check the name of the instance that you want to update, and change the instance information. The instance information is set from a PFM - RM host.

Before you change an information item, check the following table. For details about Oracle instance information, see your Oracle documentation.

Organization of this subsection
(1) Windows
(2) UNIX

(1) Windows

Table 2-29 PFM - RM for Oracle instance information

Item Description Specifiable value Default
oracle_sid The value of this item can be updated.
ID of the monitored Oracle system (same value as the ORACLE_SID environment variable).		 A character string of 255 or fewer bytes that does not include the following characters:
  • Spaces
  • Tabs
  • The following symbols:
    , < >
 Previous value
oracle_home#1 The value of this item can be updated.
Oracle home folder of Oracle client used by PFM - RM for Oracle (same value as the ORACLE_HOME environment variable). #2		 A character string of 255 or fewer bytes that does not include the following characters:
  • Spaces
  • Tabs
  • The following symbols:
    , < >
 Previous value
oracle_version#1 The value of this item can be updated.
Version number of Oracle Client used by PFM - RM for Oracle.
  • For Oracle 10g: 10
  • For Oracle 11g: 11
 Previous value
oracle_user#3 The value of this item can be updated.
Account for monitoring Oracle (for details about accounts that can be specified, and the required privileges, see 2.1.4(2) Create an Oracle account to be used in PFM - RM for Oracle).		 A character string of 255 or fewer bytes that does not include the following characters:
  • Spaces
  • Tabs
  • The following symbols:
    , < >
 Previous value
oracle_passwd#3,#4 The value of this item can be updated.
Specify the password for the account specified in oracle_user.		 A character string of 255 or fewer bytes that does not include the following characters:
  • Spaces
  • Tabs
  • The following symbols:
    , < >
 Previous value
net_service_name#1,#5 The value of this item can be updated.
Net service name of the monitored database. For details about the net service name of the monitored database, see the Oracle documentation.		 A character string of 255 or fewer bytes that does not include the following characters:
  • Spaces
  • Tabs
  • The following symbols:
    , < >
 Previous value
retry_time The value of this item can be updated.
The number of seconds for which reconnection is attempted when an authentication error is output during Oracle connection.
If an authentication error occurs after the specified period has passed, the PFM - RM for Oracle service stops. When the value is 0, the PFM - RM for Oracle service stops without retrying to re-establish connection in the event of an authentication error.
This item is enabled when startup_always is N.
The specification of this item is ignored when startup_always is Y.		 0 to 600 (in seconds). Previous value
log_path The value of this item can be updated.
Specify the absolute path name of the agent log output folder.		 A character string of 245 or fewer bytes that does not include the following characters:
  • Tabs
  • The following symbols:
    / : , ; * ? " < > |

Notes:
  • You can specify the path to a folder under the installation folder only when the default folder is set.
  • You cannot specify the path to a folder that is used as the output destination of another instance.
 Previous value
log_size The value of this item can be updated.
Specify the maximum size of each agent log file.		 1 to 32 (in kilobytes). 16 or a greater value is recommended. Previous value
timeout The value of this item can be updated.
The timeout period for Oracle access during a query.		 0, or 10 to 3600 (in seconds).
When 0 is specified, timeout monitoring is not performed. When a value from 1 to 9 is specified, it is changed to 10 at runtime.		 Previous value
sql_option#6 The value of this item can be updated.
When Y is specified, information about the following items#5 is not collected for PI_PIDB and PD_PDTS records, and the value specified by 0 or numeric_10 is set.		 { Y | N } Previous value
numeric_10 The value of this item can be updated.
When sql_option is set to Y, the value specified is set for items for which information is not collected. If sql_option is set to N, this specification is disregarded.		 0 to 99999.
Note that if the value specified exceeds the maximum value for the data format of the set field (32767 for short and 65535 for ushort), the maximum value for the data format is set.#7		 Previous value
startup_always The value of this item can be updated.
PFM - RM for Oracle may stop due to an Oracle connection error, such as when the monitored Oracle is still starting up when PFM - RM for Oracle starts up.
If Y is specified, start processing continues even if a connection error occurs. If N is specified, start processing will stop if an error occurs.		 { Y | N } Previous value
localtemp_option#8 The value of this item can be updated.
Option for switching the display of the free space of the locally managed temporary tablespace of PD_PDDB, PI_PIDB, PD_PDDF, PI_PIDF, PD_PDTF, PD_PDTS, and PD_PCTS records.
If Y is specified, display the size of the free space. If N is specified, display the size of the unallocated space.		 { Y | N } Previous value
undospace_option#9 The value of this item can be updated.
Option for switching how the value displayed as the free space in the UNDO tablespace of the PD_PDDB, PI_PIDB, PD_PDDF, PI_PIDF, PD_PDTS, and PD_PCTS records is determined.
If N is specified, the size of the unallocated space is displayed.
If Y is specified, the size of the free space is displayed.		 { Y | N } Previous value
nls_lang#10 The value of this item can be updated.
Option for specifying the character encoding used for communication between PFM - RM for Oracle and Oracle Database.		 Character code set:
  • In Japanese Windows:
    {AMERICAN_AMERICA.US7ASCII | AMERICAN_AMERICA.JA16SJISTILDE}
  • In Simplified-Chinese Windows:
    {AMERICAN_AMERICA.US7ASCII | AMERICAN_AMERICA.ZHS32GB18030}
  • Other case:
    AMERICAN_AMERICA.US7ASCII
 Previous value

#1
To monitor a monitoring target program, you need to install Oracle Client 32-bit and set the environment. Also, when executing the jpcconf inst setup command, set each item as follows:
  • oracle_home
    Specify the Oracle home for Oracle Client 32-bit.
  • oracle_version
    Specify the version of Oracle Client 32-bit.
  • net_service_name
    Specify the net service name set for Oracle Client 32-bit.
For the net service name set in Oracle Client 32-bit, specify the net service name for connecting to the monitored instance of Oracle Database.
If Oracle Client 32-bit has not been installed and the environment has not been configured, and you specify an Oracle Database in which Oracle Client 32-bit is not installed or specify ORACLE_HOME of Oracle Client 64-bit for oracle_home in the instance information and you then start PFM - RM for Oracle, the message KAVL18020-E is displayed.

#2
If PFM - RM for Oracle uses the client library of an Oracle Database in which Oracle Client 32-bit has been installed, specify the Oracle home folder of the Oracle Database.

#3
To change a user, use the following procedure:
  1. Delete the objects created by the user you want to change.
  2. Register new objects as the new user.
Performance data is not deleted when a user is changed.
For details about how to delete objects, see 2.3.2(1)(c) Deleting the objects registered in the Oracle Database. For details about how to register objects, see 2.1.4(3)(c) Registering objects in the Oracle Database.

#4
If the expiration date is set on oracle_passwd, once the password is out of date connections to Oracle fail so that PFM - RM for Oracle cannot collect the performance information. In order to avoid connection errors, perform either of the following procedures before the password is expired:
  • Unset the expiration date of the password
  • After updating password, execute the jpcconf inst setup command to update oracle_passwd.
Note that the Oracle DEFAULT profile is applied to the Oracle account created by mk_rmus.sql.

#5
Specify in advance the network service (such as tnsnames.ora) of the Oracle Client used by PFM - RM for Oracle.
Configure the network service definition (such as listener.ora) and run the listener process in advance.
When monitoring Oracle Database instances in an Oracle RAC configuration, set up the PFM - RM for Oracle so that it monitors Oracle Database instances on each node. For details about how to set up, see the Oracle documentation.
Note that the location of tnsnames.ora must be:

oracle_home\network\admin
If tnsnames.ora is located on other folder, PFM - RM for Oracle cannot connect to Oracle.

#6
To obtain each piece of Oracle segment-related information, PFM - RM for Oracle searches Oracle's static data dictionary views DBA_SEGMENTS. If a large number of segments (more than hundreds of thousands) exist for Oracle, information collection requires a significant amount of time. As such, when a large number of segments exist, and the information listed in the following table no longer needs to be collected, set the sql_option to Y during operation.

Table 2-30 Record names and the values specified for numeric_10 (updating instance information)

Record Name PFM - View name Value specified for numeric_10
PD_PDTS Segments Enabled
Extents Enabled
PI_PIDB DB Files % Enabled
Log Files % Enabled
NextAlloc Fails Enabled
Tablespaces Enabled
Rollback Segments Enabled
Rollback Segments Trans Enabled
Blocks Enabled
Segments Enabled
Extents Enabled
Free Mbytes Enabled
Overextended Enabled
High Max Extent Enabled
Datafiles Enabled
Mbytes Enabled
Free Extents Enabled
Free% Enabled
Free Change Enabled
Write% Enabled
Write/sec Enabled
Redo Files Enabled
Links Enabled
Links Logged On Enabled
Links In Tran Enabled
Links Open Cursors Enabled
Used Change Enabled
Used Mbytes Enabled
Rollback Segments Hit% Enabled
Sort Segments Enabled
Sorting Users Enabled
Physical Blocks Read Always set to 0 because it is a delta item.
Physical Blocks Written Always set to 0 because it is a delta item.
Physical Reads Always set to 0 because it is a delta item.
Physical Writes Always set to 0 because it is a delta item.

#7
If the field format for each record is float or double, since the data is a floating-point number, it may be rounded depending on the specified value.
Example:
When numeric_10 is set to 32767, it may be displayed as 32760.

#8
When localtemp_option is set to Y, collect free space of the locally managed temporary tablespace and information about the extents from v$temp_extent_pool of the dynamic performance view. The displayed values of the size of free space are calculated from the size of the used space.
When localtemp_option is set to N, collect free space of the locally managed temporary tablespace and information about the extents from v$temp_space_header of the dynamic performance view. The displayed values of the size of free space are the size of the unallocated space. Since the allocated space is not freed until the temporary tablespace is reconstructed or recreated, the displayed values of free space do not increase until the space is freed.
When issuing query to v$temp_extent_pool view, the Oracle instance goes to sleep. Since this may have effect on the performance of the Oracle instance, you need adequate consideration before localtemp_option is set to Y. For details, see your Oracle documentation.

#9
When undospace_option is set to N, the size of the unallocated space is collected as the amount of free space in the UNDO tablespace. Space in the UNDO tablespace that becomes available because its retention period has expired is treated as allocated space until it is released.
When undospace_option is set to Y, the size of the free space is collected as the amount of free space in the UNDO tablespace. Space of the UNDO tablespace that becomes available because its retention period has expired is included in the size of the free space.
The following table shows the fields whose values change depending on the specification of the undospace_option:
Record name Field name
Data File (PD_PDDF) Free %
Free Mbytes
Used Mbytes
Data File Interval
(PI_PIDF)		 Free %
Free Change
Free Mbytes
Used Change
Used Mbytes
Database (PD_PDDB) Free %
Free Mbytes
Used Mbytes
Database Interval
(PI_PIDB)		 Free %
Free Change
Free Mbytes
Used Change
Used Mbytes
Tablespace (PD_PDTS) Free %
Free Mbytes
Used Mbytes
Collection Tablespace 2
(PD_PCTS)		 Free Mbytes

#10
The following figure shows the relationship among data, language environment of the OS, and instance information handled by PFM - RM for Oracle.

Figure 2-11 Relationship between data and the setting values

[Figure]
PFM - RM for Oracle can collect performance data in SJIS (in Japanese Windows) and GB18030 (in Simplified-Chinese Windows) format as well as 7-bit ASCII format. you must specify nls_lang variable for the language environment of the OS, NLS_CHARACTERSET of the Oracle.
OS language of PFM - RM for Oracle installed NLS_CHARACTERSET of the monitored Oracle
(Database character set)		 nls_lang instance information (this item)
Japanese JA16SJISTILDE AMERICAN_AMERICA.JA16SJISTILDE or AMERICAN_AMERICA.US7ASCII#
JA16SJIS
other AMERICAN_AMERICA.US7ASCII#
Simplified-Chinese ZHS16GBK AMERICAN_AMERICA.GB18030 or AMERICAN_AMERICA.US7ASCII#
AL32UTF8
other AMERICAN_AMERICA.US7ASCII#
other language notdependent AMERICAN_AMERICA.US7ASCII#

#
Performance data is collected within the scope of 7-bit ASCII characters, likely resulting in unreadable characters.

For any other combination, performance data is collected within the scope of 7-bit ASCII characters, likely resulting in unreadable characters.
When you specify an invalid character code set for the nls_lang instance information, the message KAVL18302-W with errcode 12705 is output, and the connection with Oracle will fail.
In the following cases as well, unreadable characters might occur in the performance data:
  1. The Oracle column length is exceeded.
    If you store data that exceeds the Oracle column length, the last character might become unreadable. If you use PFM - RM for Oracle to collect data in Oracle and that data contains unreadable characters, the last character of the performance data will be unreadable.
  2. The field size of PFM - RM for Oracle is exceeded.
    PFM - RM for Oracle collects performance data of the record field size from Oracle. Therefore, if Oracle contains data that exceeds the field size, the last character of the performance data might be unreadable. The following table lists the applicable fields:
    Recode name Field name Filed size (unit: bytes)
    Parameter Values(PD_PDP) Value 512
    SQL Text(PD_PDSQ) Explain Plan 30,000
    SQL Text 30,000

Use the jpcconf inst list command to check the instance name. To update an instance environment, use the jpcconf inst setup command.

Updating an instance environment involves the steps described below. To update multiple instance environments, repeat the procedure for each instance environment.

To update an instance environment:

  1. Find the instance name.
    Execute the jpcconf inst list command specified with the service key that indicates PFM - RM for Oracle.

jpcconf inst list -key RMOracle
    If the specified instance name is SDC, the command displays SDC.
  2. If the PFM - RM for Oracle service is active in the instance environment that is to be updated, stop the service.
    For details about stopping services, see the chapter on starting and stopping Performance Management in the Job Management Partner 1/Performance Management User's Guide.
    If the service is still active in the instance environment that is to be updated when you execute the jpcconf inst setup command, a confirmation message is displayed to enable you to stop the service. If you stop the service, update processing resumes; if you do not stop the service, update processing is canceled.
  3. Execute the jpcconf inst setup command specified with the service key that indicates PFM - RM for Oracle and the instance name.
    For example, if you are updating the instance environment for the PFM - RM for Oracle with instance name SDC, execute the following command:

jpcconf inst setup -key RMOracle -inst SDC
  4. Update the instance information for Oracle.
    Enter the information shown in Table 2-29 in accordance with the command's instructions. The current settings are displayed (except for the value of oracle_passwd). To use the displayed value, press the Enter key. When you have finished entering information, the instance environment is updated.
  5. Restart the service in the updated instance environment.
    For details about starting services, see the chapter on starting and stopping Performance Management in the Job Management Partner 1/Performance Management User's Guide.

For details about commands, see the chapter on commands in the manual Job Management Partner 1/Performance Management Reference.

(2) UNIX

Table 2-31 PFM - RM for Oracle instance information

Item Description Specifiable value Default
oracle_sid The value of this item can be updated.
ID of the monitored Oracle system (same value as the ORACLE_SID environment variable).		 A character string of 255 or fewer bytes that does not include the following characters:
  • Spaces
  • Tabs
  • The following symbols:
    , < >
 Previous value
oracle_home#1 The value of this item can be updated.
The value of this item can be updated.
Oracle home folder of Oracle client used by PFM - RM for Oracle (same value as the ORACLE_HOME environment variable). #1		 A character string of 255 or fewer bytes that does not include the following characters:
  • Spaces
  • Tabs
  • The following symbols:
    , < >
 Previous value
oracle_version#1 The value of this item can be updated.
Version number of Oracle Client used by PFM - RM for Oracle.
  • For Oracle 10g: 10
  • For Oracle 11g: 11
 Previous value
oracle_user#3 The value of this item can be updated.
Account for monitoring Oracle (for details about accounts that can be specified, and the required privileges, see 2.2.4(3) Create an Oracle account to be used in PFM - RM for Oracle).#2		 A character string of 255 or fewer bytes that does not include the following characters:
  • Spaces
  • Tabs
  • The following symbols:
    , < >
 Previous value
oracle_passwd#3,#4 The value of this item can be updated.
Specify the password for the account specified in oracle_user.		 A character string of 255 or fewer bytes that does not include the following characters:
  • Spaces
  • Tabs
  • The following symbols:
    , < >
 Previous value
net_service_name#1.#5 The value of this item can be updated.
Net service name of the monitored database. For details about the net service name of the monitored database, see the Oracle documentation.		 A character string of 255 or fewer bytes that does not include the following characters:
  • Spaces
  • Tabs
  • The following symbols:
    , < >
 Previous value
log_path#6 The value of this item can be updated.
Specify the absolute path name of the agent log output folder.		 A character string of 245 or fewer bytes that does not include the following characters:
  • Tabs
  • The following symbols:
    / : , ; * ? " < > |

Notes:
  • You can specify the path to a folder under the installation folder only when the default folder is set.
  • You cannot specify the path to a folder that is used as the output destination of another instance.
 Previous value
log_size The value of this item can be updated.
Specify the maximum size of each agent log file.		 1 to 32 (in kilobytes). 16 or a greater value is recommended. Previous value
timeout The value of this item can be updated.
The timeout period for Oracle access during a query.		 0, or 10 to 3600 (in seconds).
When 0 is specified, timeout monitoring is not performed. When a value from 1 to 9 is specified, it is changed to 10 at runtime.		 Previous value
sql_option#7 The value of this item can be updated.
When Y is specified, information about the following items#6 is not collected for PI_PIDB and PD_PDTS records, and the value specified by 0 or numeric_10 is set.		 { Y | N } Previous value
numeric_10 The value of this item can be updated.
When sql_option is set to Y, the value specified is set for items for which information is not collected. If sql_option is set to N, this specification is disregarded.		 0 to 99999.
Note that if the value specified exceeds the maximum value for the data format of the set field (32767 for short and 65535 for ushort), the maximum value for the data format is set.#7		 Previous value
startup_always The value of this item can be updated.
PFM - RM for Oracle may stop due to an Oracle connection error, such as when the monitored Oracle is still starting up when PFM - RM for Oracle starts up.
If Y is specified, start processing continues even if a connection error occurs. If N is specified, start processing will stop if an error occurs.		 { Y | N } Previous value
localtemp_option#9 The value of this item can be updated.
Option for switching the display of the free space of the locally managed temporary tablespace of PD_PDDB, PI_PIDB, PD_PDDF, PI_PIDF, PD_PDTF, PD_PDTS, and PD_PCTS records.
If Y is specified, display the size of the free space. If N is specified, display the size of the unallocated space.		 { Y | N } Previous value
nls_lang#10 The value of this item can be updated.
Option for specifying the character encoding used for communication between PFM - RM for Oracle and Oracle Database.		 Character code set:
According to LANG of the OS when at the start time of the PFM - RM for Oracle.
  • UTF-8:
    {AMERICAN_AMERICA.US7ASCII | AMERICAN_AMERICA.AL32UTF8}
  • GB18030:
    {AMERICAN_AMERICA.US7ASCII | AMERICAN_AMERICA.ZHS32GB18030}
  • Other case:
    AMERICAN_AMERICA.US7ASCII
 Previous value
undospace_option#11 The value of this item can be updated.
Option for switching how the value displayed as the free space in the UNDO tablespace of the PD_PDDB, PI_PIDB, PD_PDDF, PI_PIDF, PD_PDTS, and PD_PCTS records is determined.
If N is specified, the size of the unallocated space is displayed.
If Y is specified, the size of the free space is displayed.		 { Y | N } Previous value

#1
To monitor a monitoring target program, you need to install Oracle Client 32-bit and set the environment. Also, when executing the jpcconf inst setup command, set each item as follows:
  • oracle_home
    Specify the Oracle home for Oracle Client 32-bit.
  • oracle_version
    Specify the version of Oracle Client 32-bit.
  • net_service_name
    Specify the net service name set for Oracle Client 32-bit.
For the net service name set in Oracle Client 32-bit, specify the net service name for connecting to the monitored instance of Oracle Database.
If Oracle Client 32-bit has not been installed and the environment has not been configured, and you specify an Oracle Database in which Oracle Client 32-bit is not installed or specify ORACLE_HOME of Oracle Client 64-bit for oracle_home in the instance information and you then start PFM - RM for Oracle, the message KAVL18011-E and KAVL18021-E are displayed.

#2
If PFM - RM for Oracle uses the client library of an Oracle Database in which Oracle Client 32-bit has been installed, specify the Oracle home folder of the Oracle Database.

#3
To change a user, use the following procedure:
  1. Delete the objects created by the user you want to change.
  2. Register new objects as the new user.
Performance data is not deleted when a user is changed.
For details about how to delete objects, see 2.4.2(1)(c) Deleting the objects registered in the Oracle Database. For details about how to register objects, see 2.2.4(4)(c) Registering objects in the Oracle Database.

#4
If the expiration date is set on oracle_passwd, once the password is out of date connections to Oracle fail so that PFM - RM for Oracle cannot collect the performance information. In order to avoid connection errors, perform either of the following procedures before the password is expired:
  • Unset the expiration date of the password
  • After updating password, execute the jpcconf inst setup command to update oracle_passwd.
Note that the Oracle DEFAULT profile is applied to the Oracle account created by mk_rmus.sql.

#5
Specify in advance the network service (such as tnsnames.ora) of the Oracle Client used by PFM - RM for Oracle.
Configure the network service definition (such as listener.ora) and run the listener process in advance.
When monitoring Oracle Database instances in an Oracle RAC configuration, set up the PFM - RM for Oracle so that it monitors Oracle Database instances on each node. For details about how to set up, see the Oracle documentation.
Note that the location of tnsnames.ora must be:

oracle_home/network/admin
If tnsnames.ora is located on other folder, PFM - RM for Oracle cannot connect to Oracle.

#6

Manually save the old path information in a file as history data, since the information is not saved automatically. You may need to acquire the agent log information from the old directory if a problem occurs.

#7

To obtain each piece of Oracle segment-related information, PFM - RM for Oracle searches Oracle's static data dictionary views DBA_SEGMENTS. If a large number of segments (more than hundreds of thousands) exist for Oracle, information collection requires a significant amount of time. As such, when a large number of segments exist, and the information listed in the following table no longer needs to be collected, set the sql_option to Y during operation.

Table 2-32 Record names and the values specified for numeric_10 (updating instance information)

Record Name PFM - View name Value specified for numeric_10
PD_PDTS Segments Enabled
Extents Enabled
PI_PIDB DB Files % Enabled
Log Files % Enabled
NextAlloc Fails Enabled
Tablespaces Enabled
Rollback Segments Enabled
Rollback Segments Trans Enabled
Blocks Enabled
Segments Enabled
Extents Enabled
Free Mbytes Enabled
Overextended Enabled
High Max Extent Enabled
Datafiles Enabled
Mbytes Enabled
Free Extents Enabled
Free% Enabled
Free Change Enabled
Write% Enabled
Write/sec Enabled
Redo Files Enabled
Links Enabled
Links Logged On Enabled
Links In Tran Enabled
Links Open Cursors Enabled
Used Change Enabled
Used Mbytes Enabled
Rollback Segments Hit% Enabled
Sort Segments Enabled
Sorting Users Enabled
Physical Blocks Read Always set to 0 because it is a delta item.
Physical Blocks Written Always set to 0 because it is a delta item.
Physical Reads Always set to 0 because it is a delta item.
Physical Writes Always set to 0 because it is a delta item.

#8
If the field format for each record is float or double, since the data is a floating-point number, it may be rounded depending on the specified value.
Example:
When numeric_10 is set to 32767, it may be displayed as 32760.

#9
When localtemp_option is set to Y, collect free space of the locally managed temporary tablespace and information about the extents from v$temp_extent_pool of the dynamic performance view. The displayed values of the size of free space are calculated from the size of the used space.
When localtemp_option is set to N, collect free space of the locally managed temporary tablespace and information about the extents from v$temp_space_header of the dynamic performance view. The displayed values of the size of free space are the size of the unallocated space. Since the allocated space is not freed until the temporary tablespace is reconstructed or recreated, the displayed values of free space do not increase until the space is freed.
When issuing query to v$temp_extent_pool view, the Oracle instance goes to sleep. Since this may have effect on the performance of the Oracle instance, you need adequate consideration before localtemp_option is set to Y. For details, see your Oracle documentation.

#10
The following figure shows the relationship among data, LANG environment variable of at the start time of the PFM - RM for Oracle, and instance information handled by PFM - RM for Oracle.

Figure 2-12 Relationship between data and the setting values

[Figure]
PFM - RM for Oracle can collect performance data in UTF-8 and GB18030 format as well as 7-bit ASCII format. To collect performance data in UTF-8 or GB18030 format, you must specify UTF-8 or GB18030 for the language settings of the OS, and PFM - RM for Oracle.
The following table shows the combination of LANG setting of at the start time of the PFM - RM for Oracle for collecting performance data in UTF-8 and GB18030 format:
LANG environment variable of at the start time of PFM - RM for Oracle nls_lang instance information
(this item)
ja_JP.UTF-8,
ja_JP.utf-8,
zh_CN.UTF-8,
zh_CN.utf8		 AMERICAN_AMERICA.AL32UTF8 or AMERICAN_AMERICA.US7ASCII#
zh_CN.gb18030 AMERICAN_AMERICA.ZHS32GB18030 or AMERICAN_AMERICA.US7ASCII#
other LANG AMERICAN_AMERICA.US7ASCII#

#
Performance data is collected within the scope of 7-bit ASCII characters, likely resulting in unreadable characters.

For any other combination, performance data is collected within the scope of 7-bit ASCII characters, likely resulting in unreadable characters.
For details about how to set the LANG environment variable of the OS, see 2.2.4(1) Set the LANG environment variable.
When you specify an invalid character code set for the nls_lang instance information, the message KAVL18302-W with errcode 12705 is output, and connection with Oracle will fail.
In the following cases as well, unreadable characters might occur in the performance data:
  1. The Oracle column length is exceeded.
    If you store data that exceeds the Oracle column length, the last character might become unreadable. If you use PFM - RM for Oracle to collect data in Oracle that contains unreadable characters, the last character of the performance data will be unreadable.
  2. The field size of PFM - RM for Oracle is exceeded.
    PFM - RM for Oracle collects performance data of the record field size from Oracle. Therefore, if Oracle contains data that exceeds the field size, the last character of the performance data might be unreadable. The following table lists the applicable fields:
    Record name Field name Field size
    (Unit: bytes)
    Collection Instance 2 (PD_PCI) Host 30
    Data File (PD_PDDF) File Name 255
    Data File Interval (PI_PIDF) File Name 255
    Instance (PD_PDI) Host 30
    Minimum Data File Interval 2 (PI_PMDF) File Name 255
    Parameter Values (PD_PDP) Value 512
    SQL Text (PD_PDSQ) Explain Plan 30000
    SQL Text 30000
  3. Unreadable or lack of characters in deferent between database character set of the Oracle and nls_lang instance variable of the PFM - RM for Oracle.
    A data of 2 bytes on the basis of Oracle may be collected at 3 bytes when you set AMERICAN_AMERICA.AL32UTF8 in nls_lang and a database character set for the monitoring is not UTF-8. Therefore, if performance data takes from ORACLE that exceeds the field size, the last character of the performance data might be unreadable. The following table lists the applicable fields:
    Record name Field name Field size
    (Unit: bytes)
    Collection Tablespace 2(PD_PCTS) Tablespace Name 30
    Data File(PD_PDDF) File Name 255
    Tablespace Name 30
    Data File Interval(PI_PIDF) File Name 255
    Tablespace Name 30
    Database(PD_PDDB) DB Name 9
    Database Interval(PI_PIDB) DB Name 9
    Instance(PD_PDI) Host 30
    Lock Waiters(PD_PDLW) Holding User 30
    Waiting User 30
    Minimum Database Interval 2(PI_PMDB) DB Name 9
    Minimum Data File Interval 2(PI_PMDF) File Name 513
    Minimum Tablespace Interval 2(PI_PMTS) Tablespace Name 30
    Open Cursor(PD_PDOC) Program 48
    SQL Text 60
    Parameter Values(PD_PDP) Value 512
    Session Detail(PD_PDS) Machine 64
    Module 48
    OS User 30
    Program 64
    Schema Name 30
    User 30
    Session I/O Interval(PI_PIIO) User 30
    Session Statistics Summary(PD_PDS2) Program 48
    User 30
    SQL Text(PD_PDSQ) Explain Plan 30,000
    SQL Text 30,000
    Tablespace Flagmentation(PD_PDTF) Tablespace Name 30
    Tablespace Interval(PI_PITS) Tablespace Name 30
    Tablespace(PD_PDTS) Tablespace Name 30
    Transaction(PD_PDTR) User 30
    Tranasction Lock(PD_PDTL) Object Name 30
    Owner 30
    User 30

#11
When undospace_option is set to N, the size of the unallocated space is collected as the amount of free space in the UNDO tablespace. Space in the UNDO tablespace that becomes available because its retention period has expired is treated as allocated space until it is released.
When undospace_option is set to Y, the size of the free space is collected as the amount of free space in the UNDO tablespace. Space of the UNDO tablespace that becomes available because its retention period has expired is included in the size of the free space.
The following table shows the fields whose values change depending on the specification of the undospace_option:
Record name Field name
Data File (PD_PDDF) Free %
Free Mbytes
Used Mbytes
Data File Interval
(PI_PIDF)		 Free %
Free Change
Free Mbytes
Used Change
Used Mbytes
Database (PD_PDDB) Free %
Free Mbytes
Used Mbytes
Database Interval
(PI_PIDB)		 Free %
Free Change
Free Mbytes
Used Change
Used Mbytes
Tablespace (PD_PDTS) Free %
Free Mbytes
Used Mbytes
Collection Tablespace 2
(PD_PCTS)		 Free Mbytes

Use the jpcconf inst list command to check the instance name. To update an instance environment, use the jpcconf inst setup command.

Updating an instance environment involves the steps described below. To update multiple instance environments, repeat the procedure for each instance environment.

To update an instance environment:

  1. Find the instance name.
    Execute the jpcconf inst list command specified with the service key that indicates PFM - RM for Oracle.

jpcconf inst list -key RMOracle
    If the specified instance name is SDC, the command displays SDC.
  2. If the PFM - RM for Oracle service is active in the instance environment that is to be updated, stop the service.
    For details about stopping services, see the chapter on starting and stopping Performance Management in the Job Management Partner 1/Performance Management User's Guide.
    If the service is still active in the instance environment that is to be updated when you execute the jpcconf inst setup command, a confirmation message is displayed to enable you to stop the service. If you stop the service, update processing resumes; if you do not stop the service, update processing is canceled.
  3. Execute the jpcconf inst setup command specified with the service key that indicates PFM - RM for Oracle and the instance name.
    For example, if you are updating the instance environment for the PFM - RM for Oracle with instance name SDC, execute the following command:

jpcconf inst setup -key RMOracle -inst SDC
  4. Update the instance information for Oracle.
    Enter the information shown in Table 2-29 in accordance with the command's instructions. The current settings are displayed (except for the value of oracle_passwd). To use the displayed value, press the Enter key. When you have finished entering information, the instance environment is updated.
  5. Restart the service in the updated instance environment.
    For details about starting services, see the chapter on starting and stopping Performance Management in the Job Management Partner 1/Performance Management User's Guide.

For details about commands, see the chapter on commands in the manual Job Management Partner 1/Performance Management Reference.

[Contents][Back][Next]

[Trademarks]

Copyright (C) 2013, Hitachi, Ltd.
Copyright (C) 2013, Hitachi Solutions, Ltd.
