Job Management Partner 1/Integrated Management - Manager Overview and System Design Guide

Preface

This manual provides an overview and describes the functionality and system design of Job Management Partner 1/Integrated Management - Manager and Job Management Partner 1/Integrated Management - View.

In this manual, Job Management Partner 1 is abbreviated as JP1, and JP1/Integrated Management is abbreviated as JP1/IM.

The JP1/IM series includes a number of other program products, which are mentioned in this manual as outlined in the table below. For further details, see the documentation accompanying the product.

Product name	Contents covered in this manual
JP1/IM - Rule Operation	The role of JP1/IM - Rule Operation within the JP1/IM series An overview of the JP1/IM - Rule Operation linkage function
JP1/IM - Event Gateway for Network Node Manager i	The role of JP1/IM - Event Gateway for Network Node Manager i within the JP1/IM series

Intended readers

This manual is intended for those responsible for managing and operating the management infrastructure for an open-platform system using JP1/IM. Specifically, this manual is intended for:

• System administrators, system designers, and operators who want to centrally manage the events occurring in the system and take some form of action to resolve them.
• System administrators, system designers, and operators who want to centrally monitor the system management infrastructure by associating its status with events occurring in the system.

Organization of this manual

This manual is organized into the following parts:

PART 1: Overview

This part provides an overview of the JP1/IM series and JP1/IM - Manager.

PART 2: Functionality

This part describes the functionality of JP1/IM.

PART 3: Design

This part describes the requirements for the monitoring tasks supported by JP1/IM and the system requirements for achieving those objectives.

Related publications

This manual is part of a related set of manuals. The manuals in the set are listed below (with the manual numbers):

JP1/IM-related

• Job Management Partner 1/Integrated Management - Manager Quick Reference (3020-3-R75(E))
• Job Management Partner 1/Integrated Management - Manager Configuration Guide (3020-3-R77(E))
• Job Management Partner 1/Integrated Management - Manager Administration Guide (3020-3-R78(E))
• Job Management Partner 1/Integrated Management - Manager GUI Reference (3020-3-R79(E))
• Job Management Partner 1/Integrated Management - Manager Command and Definition File Reference (3020-3-R80(E))
• Job Management Partner 1/Integrated Management - Manager Messages (3020-3-R81(E))
• Job Management Partner 1/Integrated Management - Event Gateway for Network Node Manager i Description, User's Guide and Reference (3020-3-R82(E))
• Job Management Partner 1/Integrated Management - Rule Operation System Configuration and User's Guide (3020-3-K10(E))
• Job Management Partner 1/Integrated Management - Rule Operation GUI Reference (3020-3-K11(E))

JP1-related

• Job Management Partner 1/Performance Management Planning and Configuration Guide (3020-3-R31(E))
• Job Management Partner 1/Base User's Guide (3020-3-R71(E))
• Job Management Partner 1/Base Messages (3020-3-R72(E))
• Job Management Partner 1/Base Function Reference (3020-3-R73(E))
• Job Management Partner 1/Automatic Job Management System 3 Linkage Guide (3020-3-S12(E))
• Job Management Partner 1/Automatic Job Management System 2 Linkage Guide (3020-3-K27(E))

Conventions: Abbreviations

This manual uses the following abbreviations for the names of Hitachi products and other products:

Abbreviation		Full name or meaning
AIX		AIX(R) 5L 5.2
		AIX(R) 5L 5.3
		AIX(R) 6.1
Cosminexus	Cosminexus Application Server	uCosminexus Application Server Standard
		uCosminexus Application Server Enterprise
		uCosminexus Web Redirector
		uCosminexus Service Platform
HNTRLib		Hitachi Network Objectplaza Trace Library
HNTRLib2		Hitachi Network Objectplaza Trace Library 2
HP-UX	HP-UX (IPF)	HP-UX 11i V2(IPF)
		HP-UX 11i V3(IPF)
IE	Microsoft Internet Explorer	Microsoft(R) Internet Explorer(R)
	Windows Internet Explorer	Windows(R) Internet Explorer(R)
IIS	Internet Information Services	Microsoft(R) Internet Information Services 5.01 or later
JP1/AJS	JP1/AJS2 - Advanced Manager	Job Management Partner 1/Automatic Job Management System 2 - Advanced Manager
	JP1/AJS - Agent	Job Management Partner 1/Automatic Job Management System 2 - Agent
		Job Management Partner 1/Automatic Job Management System 3 - Agent
	JP1/AJS - Manager	Job Management Partner 1/Automatic Job Management System 2 - Manager
		Job Management Partner 1/Automatic Job Management System 3 - Manager
	JP1/AJS - View	Job Management Partner 1/Automatic Job Management System 2 - View
		Job Management Partner 1/Automatic Job Management System 3 - View
JP1/AJS2 - Scenario Operation View		Job Management Partner 1/Automatic Job Management System 2 - Scenario Operation View
JP1/AJS2 - View for Mainframe		Job Management Partner 1/Automatic Job Management System 2 - View for Mainframe
JP1/Base		Job Management Partner 1/Base
JP1/Cm2/ESA		Job Management Partner 1/Cm2/Extensible SNMP Agent
		Job Management Partner 1/Cm2/Extensible SNMP Agent for Extension Mib Runtime
JP1/FTP		Job Management Partner 1/File Transmission Server/FTP
JP1/Integrated Management or JP1/IM	Version 7 products
	JP1/IM - Central Console or JP1/IM - CC	Job Management Partner 1/Integrated Manager - Central Console
	JP1/IM - Central Console upgrade or JP1/IM - CC upgrade	Job Management Partner 1/Integrated Manager - Central Console upgrade
	JP1/IM - View	Job Management Partner 1/Integrated Manager - View
	Version 8 products
	JP1/IM - Manager	Job Management Partner 1/Integrated Management - Manager
	JP1/IM - Rule Operation or JP1/IM - RL#	Job Management Partner 1/Integrated Management - Rule Operation
	JP1/IM - View	Job Management Partner 1/Integrated Management - View
	Version 9 products
	JP1/IM - Event Gateway for Network Node Manager i or JP1/IM - EG for NNMi#	Job Management Partner 1/Integrated Management - Event Gateway for Network Node Manager i
	JP1/IM - Manager	Job Management Partner 1/Integrated Management - Manager
	JP1/IM - View	Job Management Partner 1/Integrated Management - View
JP1/PAM	JP1/PA - Adaptor	Job Management Partner 1/Performance Analysis - Adaptor
		Job Management Partner 1/Performance Management - Analysis Adaptor
	JP1/PA - Manager	Job Management Partner 1/Performance Analysis - Manager
		Job Management Partner 1/Performance Management - Analysis Manager
	JP1/PA - View	Job Management Partner 1/Performance Analysis - View
		Job Management Partner 1/Performance Management - Analysis View
JP1/PFM	JP1/PFM - Agent	Job Management Partner 1/Performance Management - Agent for Platform, and other agent product names
	JP1/PFM - Manager	Job Management Partner 1/Performance Management - Manager
	JP1/PFM - View	Job Management Partner 1/Performance Management - View
	JP1/PFM - Web Console	Job Management Partner 1/Performance Management - Web Console
JP1/SES		Job Management Partner 1/System Event Service
JP1/Software Distribution		Job Management Partner 1/Software Distribution Manager
		Job Management Partner 1/Software Distribution SubManager
		Job Management Partner 1/Software Distribution Client
NNM	HP NNM	HP Network Node Manager Software version 6 or earlier
		HP Network Node Manager Starter Edition Software version 7.5 or earlier
NNMi	HP NNMi	HP Network Node Manager i Software v8.10
Solaris		Solaris 9
		Solaris 10
VMware		VMware(R) ESX 3.5
Windows 2000		Microsoft(R) Windows(R) 2000 Advanced Server Operating System
		Microsoft(R) Windows(R) 2000 Professional Operating System
		Microsoft(R) Windows(R) 2000 Server Operating System
Windows Server 2003	Windows Server 2003	Microsoft(R) Windows Server(R) 2003, Enterprise Edition
		Microsoft(R) Windows Server(R) 2003, Standard Edition
	Windows Server 2003(IPF)	Microsoft(R) Windows Server(R) 2003, Enterprise Edition for Itanium-based Systems
	Windows Server 2003(x64)	Microsoft(R) Windows Server(R) 2003, Enterprise x64 Edition
		Microsoft(R) Windows Server(R) 2003, Standard x64 Edition
	Windows Server 2003 R2	Microsoft(R) Windows Server(R) 2003 R2, Enterprise Edition
		Microsoft(R) Windows Server(R) 2003 R2, Standard Edition
	Windows Server 2003 R2(x64)	Microsoft(R) Windows Server(R) 2003 R2, Enterprise x64 Edition
		Microsoft(R) Windows Server(R) 2003 R2, Standard x64 Edition
Windows Server 2008		Microsoft(R) Windows Server(R) 2008 Enterprise
		Microsoft(R) Windows Server(R) 2008 Standard
Windows Server 2008(IPF)		Microsoft(R) Windows Server(R) 2008 for Itanium-based Systems
Windows Vista		Microsoft(R) Windows Vista(R) Business
		Microsoft(R) Windows Vista(R) Enterprise
		Microsoft(R) Windows Vista(R) Ultimate
Windows XP Professional		Microsoft(R) Windows(R) XP Professional Operating System

#: In this manual, only the JP1/IM - Rule Operation and JP1/IM - Event Gateway for Network Node Manager i functionality related to JP1/IM - Manager and JP1/IM - View is described in broad outline.

• Windows is sometimes used generically, referring to Windows 2000, Windows XP Professional, Windows Server 2003, Windows Vista, Windows Server 2008, and Windows Server 2008 (IPF).
• UNIX is sometimes used generically, referring to HP-UX, Solaris, and AIX.

This manual also uses the following abbreviations:

Abbreviation	Full name or meaning
ASCII	American Standard Code for Information Interchange
CMT	Container-Managed Transaction
CRLF	Carriage Return/Line Feed
CSV	Comma Separated Value
DB	Database
DBMS	Database Management System
DNS	Domain Name System
FQDN	Fully Qualified Domain Name
GMT	Greenwich Mean Time
GUI	Graphical User Interface
HTML	Hyper Text Markup Language
HTTP	HyperText Transfer Protocol
IP	Internet Protocol
IPF	Itanium(R) Processor Family
ISAM	Indexed Sequential Access Method
J2EE	JavaTM2 Platform Enterprise Edition
Java VM	JavaTM Virtual Machine
JDBC	JavaTM DataBase Connectivity
LAN	Local Area Network
NAT	Network Address Translator
NIC	Network Interface Card
NTP	Network Time Protocol
OTS	Object Transaction Service
POSIX	Portable Operating System Interface for UNIX
SFO	Session Fail Over
SNMP	Simple Network Management Protocol
TCP/IP	Transmission Control Protocol/Internet Protocol
TXT	Text
UAC	User Account Control
UCS	Universal Multiple-Octet Coded Character Set
UNC	Universal Naming Convention
URL	Uniform Resource Locator
UTC	Universal Time Coordinated
UTF	UCS Transformation Format
WAN	Wide Area Network
WWW	World Wide Web

Conventions: Default installation folders of the Windows version of JP1/IM and JP1/Base

In this manual, the default installation folders of JP1/IM and JP1/Base for Windows are represented as follows:

Product name	Installation folder notation	Default installation folder#
JP1/IM - View	view-path	system-drive:\Program Files\HITACHI\JP1CoView
JP1/IM - Manager	manager-path	system-drive:\Program Files\HITACHI\JP1IMM
	console-path	system-drive:\Program Files\HITACHI\JP1Cons
	scope-path	system-drive:\Program Files\HITACHI\JP1Scope
JP1/Base	base-path	system-drive:\Program Files\HITACHI\JP1Base

#: Represents the installation folder when the product is installed in the default location.

For Windows Server 2008 and Windows Vista, the part represented by system-drive:\Program Files is determined at installation by an OS environment variable and might differ depending on the environment.

Conventions: Diagrams

This manual uses the following conventions in diagrams:

Conventions: Fonts and symbols

Font and symbol conventions are classified as:

• General font conventions
• Conventions in syntax explanations

These conventions are described below.

General font conventions

The following table lists the general font conventions:

Font	Convention
Bold	Bold type indicates text on a window, other than the window title. Such text includes menus, menu options, buttons, radio box options, or explanatory labels. For example, bold is used in sentences such as the following: From the File menu, choose Open. Click the Cancel button. In the Enter name entry box, type your name.
Italics	Italics are used to indicate a placeholder for some actual text provided by the user or system. Italics are also used for emphasis. For example: Write the command as follows: copy source-file target-file Do not delete the configuration file.
Code font	A code font indicates text that the user enters without change, or text (such as messages) output by the system. For example: At the prompt, enter dir. Use the send command to send mail. The following message is displayed: The password is incorrect.

Examples of coding and messages appear as follows (although there may be some exceptions, such as when coding is included in a diagram):

MakeDatabase
...
StoreDatabase temp DB32

In examples of coding, an ellipsis (...) indicates that one or more lines of coding are not shown for purposes of brevity.

Conventions in syntax explanations

Syntax definitions appear as follows:

StoreDatabase [temp|perm] (database-name ...)

The following table lists the conventions used in syntax explanations:

Example font or symbol	Convention
StoreDatabase	Code-font characters must be entered exactly as shown.
database-name	This font style marks a placeholder that indicates where appropriate characters are to be entered in an actual command.
SD	Bold code-font characters indicate the abbreviation for a command.
perm	Underlined characters indicate the default value.
[ ]	Square brackets enclose an item or set of items whose specification is optional.
|	Only one of the options separated by a vertical bar can be specified at the same time.
...	An ellipsis (...) indicates that the item or items enclosed in ( ) or [ ] immediately preceding the ellipsis may be specified as many times as necessary.
()	Parentheses indicate the range of items to which the vertical bar (|) or ellipsis (...) is applicable.
{ }	One of the items enclosed in curly brackets and separated by a vertical bar must be specified.

Conventions: KB, MB, GB and TB

This manual uses the following conventions:

• 1 KB (kilobyte) is 1,024 bytes.
• 1 MB (megabyte) is 1,024² bytes.
• 1 GB (gigabyte) is 1,024³ bytes.
• 1 TB (terabyte) is 1,024⁴ bytes.

Conventions: Mathematical expressions

This manual uses the following symbols in mathematical expressions:

Symbol	Meaning
x	Multiplication sign
/	Division sign

Conventions: Meaning of "Administrators permissions"

In this manual, Administrators permissions refers to Administrators permissions for the local PC. The local user, domain user, or user of the Active Directory environment can perform tasks requiring Administrators permissions if granted Administrators permissions for the local PC.

Conventions: Version numbers

The version numbers of Hitachi program products are usually written as two sets of two digits each, separated by a hyphen. For example:

• Version 1.00 (or 1.0) is written as 01-00.
• Version 2.05 is written as 02-05.
• Version 2.50 (or 2.5) is written as 02-50.
• Version 12.25 is written as 12-25.

The version number might be shown on the spine of a manual as Ver. 2.00, but the same version number would be written in the program as 02-00.

Online manual

JP1/IM comes with an HTML manual that you can read in either of the following Web browsers:

• Microsoft Internet Explorer 6.0 or later
• Windows Internet Explorer 7 or later

The HTML manual has the same contents as this manual.

To view the HTML manual:

• In JP1/IM - View, choose Help and then Help Contents. Alternatively, from the Start menu choose Programs, JP1_Integrated Management - View, and then Help.

Note:

• Depending on the OS settings, the HTML manual might appear in the active window when opened from the Start menu.

[Contents][Back][Next]

All Rights Reserved. Copyright (C) 2009, Hitachi, Ltd.
